Chloroquine (CQ) and hydroxychloroquine (HCQ) are well-known 4-aminoquinoline antimalarial agents. Scientific evidence also supports the use of CQ and HCQ in the treatment of cancer. Overall, preclinical studies support CQ and HCQ use in anti-cancer therapy, especially in combination with conventional anti-cancer treatments since they are able to sensitise tumour cells to a variety of drugs, potentiating the therapeutic activity. Thus far, clinical results are mostly in favour of the repurposing of CQ. However, over 30 clinical studies are still evaluating the activity of both CQ and HCQ in different cancer types and in combination with various standard treatments. Interestingly, CQ and HCQ exert effects both on cancer cells and on the tumour microenvironment. In addition to inhibition of the autophagic flux, which is the most studied anti-cancer effect of CQ and HCQ, these drugs affect the Toll-like receptor 9, p53 and CXCR4-CXCL12 pathway in cancer cells. In the tumour stroma, CQ was shown to affect the tumour vasculature, cancer-associated fibroblasts and the immune system. The evidence reviewed in this paper indicates that both CQ and HCQ deserve further clinical investigations in several cancer types. Special attention about the drug (CQ versus HCQ), the dose and the schedule of administration should be taken in the design of new trials.Keywords: Repurposing Drugs in Oncology (ReDO) project, drug repositioning, chloroquine (CQ), hydroxychloroquine (HCQ), neoplasms, antineoplastic agents, anti-malarial agents Go to:
Chloroquine (CQ) and hydroxychloroquine (HCQ) are both 4-aminoquinoline agents that have been used for more than 70 and 50 years, respectively, to prevent or to treat malarial infections and later also for treating discoid and systemic lupus erythematosus and rheumatoid arthritis. Although HCQ and CQ differ only by one hydroxyl group, the addition of this hydroxyl group results in an important decrease in toxicity, while the efficacy remains constant, at least for malaria . Both drugs are available as generic products and mentioned on the WHO list of essential medicines. Frequently used trade names of CQ include Avloclor, Nivaquine or Aralen, and the most frequently used trade name for HCQ is Plaquenil.
The dosage of CQ depends on the indication [3, 4]. It should be noted that CQ is often marketed as chloroquine phosphate (CQ-phosphate) in tablets of 250 mg, which corresponds to about 150 mg of CQ. All doses mentioned below are doses of CQ-phosphate. High doses (1 g of CQ-phosphate per day) are administered in acute phases of malaria or amoebic hepatitis, but only for one or two days. The usual dose for long-term use (rheumatoid arthritis and lupus) is 250 mg of CQ-phosphate per day. For HCQ, doses for long-term use range between 200 and 400 mg per day. Long-term administration of CQ and HCQ in children is not recommended, but doses for long-term treatment between 2 and 5 mg/kg for HCQ have been reported .Go to:
Short-term administration of CQ or HCQ rarely causes severe side effects. Longer exposure has been associated with some serious though uncommon adverse events , including cardiomyopathy , irreversible retinal toxicity [9, 10], bone marrow suppression  and hypoglycaemia . The risk of retinopathy is increased with large cumulative doses of HCQ (>1000 g). However, daily doses up to 400 mg of HCQ or 250 mg CQ for several years are considered to carry an acceptable risk for CQ-induced retinopathies, with the exception of individuals of short stature . It is advised that patients receiving chronic CQ or HCQ therapy be monitored through regular ophthalmic examinations (3–6 month intervals), full blood counts and blood glucose level checks. CQ has been associated with some cases of diffuse parenchymal lung disease and drug rash with eosinophilia and systemic symptoms (DRESS) syndrome . In case of long-term HCQ exposure, skeletal muscle function and tendon reflexes should be monitored for weakness.
For both CQ and HCQ, specific caution is advised in patients suffering from impaired hepatic function (especially when associated with cirrhosis), porphyria, renal disease, epilepsy, psoriasis, glucose-6-phosphate dehydrogenase deficiency and known hypersensitivity to 4-aminoquinoline compounds .Go to:
CQ and HCQ are amphiphilic weak bases with the ability to cross cell membranes easily, which is important for their mechanism of action in malaria treatment and prophylaxis. CQ and HCQ are partially protonated at the physiologic pH (7.4), but they can be trapped in lysosomes (pH 4–5) because of bi-protonation . CQ has pKa values of 8.4 and 10.2, while HCQ has pKa values of 8.3 and 9.7 [14, 15].
Both CQ and HCQ have a high bioavailability, 89% and 74% respectively, and a large distribution volume after oral administration. Roughly, 50%–70% of CQ is protein-bound in the plasma . The terminal elimination half-life of CQ is 1–2 months and for HCQ approximately 50 days in blood (32 days in plasma). Both drugs are partially metabolised by hepatic dealkylation, but they differ in the number of the metabolites produced. The active metabolites of CQ are monodesethylchloroquine and bisdesethylchloroquine, while HCQ has one extra active metabolite, namely desethylhydroxychloroquine. Moreover, CQ and HCQ are slowly excreted and may still be detected in urine several months after administration [3, 4, 9].Go to:
Pre-clinical evidence in cancer—in vivo
CQ and HCQ have been extensively studied both in vitro and in vivo in various cancer types. This paper focuses on the results from in vivo research, since this is most relevant to clinical practice. Both drugs can be administered as monotherapy or as adjuvant agents to increase the efficacy and to limit drug resistance of standard anti-cancer therapy.
Table 1 lists the main characteristics [animal models, tumour types, animal (H)CQ doses and human equivalent doses (HED)] of the in vivo studies performed with CQ or HCQ alone.
In vivo studies investigating the efficacy of CQ and HCQ monotherapy.
|Reference||Animal model||Tumour type||Animal (H)CQ dose||HED|
|Jutten et al ||NMRI-nu (nu/nu) female mice||Xenografts of U373-EGFRwt and U373 control cells||CQ: 60 mg/kg/day for seven consecutive days (IP)||292 mg/day|
|Kim et al ||NMRI nude mice||Xenografts of U87MG cells||CQ: Intracranial administration of 5μl with a concentration of 30 mM/day for 17 days||/|
|Song et al ||Male athymic BALB/c nu/nu mice||Xenografts of CD133+ and CD133- cells isolated from Huh 7 cells||CQ: 60 mg/kg, twice weekly (IP)||292 mg twice weekly|
|Hu et al ||Nude mice||Xenograft of HepG2-GFP|
|CQ: 80 mg/kg twice daily, on a 3-day-on/2-day-off schedule for 25 days (SC)||398 mg twice daily (3 day-on/2 day-off)|
|Lakhter et al ||NOD-SCID mice||Xenografts of SKMel23 cells||CQ: 25 mg/kg, twice weekly for 3 weeks (IP)||122 mg twice weekly|
|Zheng et al ||Female BALB/c mice||Transplantation of CT26 cells||CQ: 50 or 25 mg/kg/day for 28 days (IP)||243 or 122 mg/day|
|Jiang et al ||Female BALB/c mice||Transplantation of 4T1 mouse cells||CQ: 50 or 25 mg/kg/day for 28 days (IP)||243 or 122 mg/day|
|Loehberg et al ||Wistar-Furth virgin female rats||NMU-induced mammary adenocarcinoma (IP, 50 mg/kg)||CQ: 3.5 mg/kg/week for 3 weeks (IP)||34 mg/week|
|Loehberg et al ||BALB/c mice||Transplantation of mammary ducts from 7- to 8-week-old p53-null BALB/c mice||CQ: 3.5 mg/kg/week for 8 weeks (IP)||17 mg/week|
|Maclean et al ||ATM-null, p53-null mice (C57BL/6J) or Eμ-Myc transgenic mice (C57BL/6J)||Lymphoma||CQ: 3.5 mg/kg, every 5 days (combined oral/IP or IP alone)||17 mg every 5 days|
|Sun et al ||Male Sprague Dawley rats||DEN-induced hepatocarcinoma||CQ: 50 mg/kg, every 3 days during week 0 to 9 or during week 10 to 17 (IP)||486 mg every 3 days|
|Maes et al ||Immunocompetent syngeneic (C57/Bl6) or immunodeficient(nu/nu) mice||Xenografts of A375m and transplantation of B16-F10 mouse cells||CQ: 50 or 100 mg/kg/day (IP)||243 or 486 mg/day|
|Maycotte et al ||Female Nude nu/nu mice||Xenografts of MCF7 and MDAMB231 cells||CQ: 60 mg/kg/day (IP)||292 mg/day|
|Yang et al ||NCr nude mice (Taconic)||Xenografts of 8988T, H460 cells, and panc1 cells and an orthotopic PDAC model with 8988T cells grown in the pancreata||CQ: 60 mg/kg/day (IP)||292 mg/day|
|Hiraki et al ||Bashford cancer, Ehrlich ascites and solid cancer, MH134 tumour maintained in inbred strains Strong A, C3H, RIll, and RF mice, Yoshida ascites and solid tumours carried in Wistar and random-bred rats, and Brown-Pearce carcinoma transplanted in albino male rabbits||CQ: 6 – 15 mg/kg/day (IP, IV, SC, oral)||58 – 292 mg/day|
|Pellegrini et al ||Female NMRI nu/nu mice||Xenografts of HCT116 and HT29 cells||CQ: 20 mg/kg, every 2 days for 16 days (IP)||97 mg every 2 days|
|Dutta et al ||Female inbred F344 rats||Transplantation of R3230AC mammary adenocarcinoma||CQ: 45 mg/kg, 5 days a week for 25 days (IP)||438 mg 5 days a week|
|Yamaguchi et al ||Adult female C3H/HeN mice and adult male dd-mice||Transplantation of spontaneous C3H mammary carcinoma, Bashford carcinoma 63 and Ehrlich ascites tumours||CQ: 0.2 mg/2 days for 12 days (IP)||/|
|Chi et al ||Transgenic flies (Drosophila)||RasV12 tumours||CQ- containing medium (final concentration: 1 mg/ml)||/|
|Rosenfeldt et al ||KrasG12D/-p53-/- and KrasG12D/-p53+/+ mice||Pancreatic ductal adenocarcinoma||HCQ: 60 mg/kg/day (IP)||292 mg/day|
Abbreviations: CQ (chloroquine), HCQ (hydroxychloroquine), EGFR (epidermal growth factor receptor), IP (intraperitoneal), NOD SCID mice (non-obese diabetic, severe combined immunodeficiency mice), NMU (N-methyl-N-nitrosourea), ATM (ataxia telangiectasia mutated), DEN (diethylnitrosamine), IV (intravenous), SC (subcutaneous), HED (Human Equivalent Dose).
Starting with in vivo studies that observed beneficial effects of CQ administration in cancer, Jutten et al noted a delayed tumour growth in mice bearing epidermal growth factor receptor (EGFR)-overexpressing glioblastoma xenografts in response to CQ administration. In addition, the time to reach four times the initial tumour volume was significantly longer in the CQ-treated group . Kim et al confirmed this observation in another glioblastoma xenograft mouse study, where CQ was injected intracranially. They observed that the number of mitotic cells was significantly reduced and the number of apoptotic cells was increased after CQ administration . In addition, a significant reduction of tumour volume and tumour incidence was shown by Song et al  in mice bearing liver cancer stem cells and Hu et al  observed significant tumour growth and weight reduction in an orthotopic xenograft model of liver cancer after CQ administration. Lakhter et al  demonstrated that CQ significantly reduced both tumour volume and tumour mass in a human melanoma xenograft model. Zheng et al  showed reduced tumour progression and prolonged survival time (not significant) in colon cancer-bearing mice when administering either 25 or 50 mg/kg of CQ.
Doses of 25 and 50 mg/kg of CQ both significantly increased survival time and reduced primary tumour volume in mice implanted with a highly metastasizing breast cancer cell line, as shown by Jiang et al. Interestingly, the number and diameter of lung metastases was reduced as well, and CQ enhanced tumour cell apoptosis in the high dose group .
The incidence of mammary tumours and their growth rate was significantly lower and tumour onset was delayed in CQ-pre-treated rats after being subjected to mammary adenocarcinoma induction using N-methyl-N-nitrosourea (NMU), as shown by Loehberg et al. In wild-type BALB/c mice transplanted with mammary ducts of BALB/c p53-null mice, CQ pre-treatment did not affect tumour incidence . Maclean et al confirmed that CQ could not prevent spontaneous tumour formation in p53-deficient mice. In contrast, intermittent CQ administration significantly reduced the tumour development and doubled the overall survival (OS) of Eμ-Myc mice .
Furthermore, Sun et al showed that CQ administration is effective in reducing tumour growth in rats with established hepatocarcinoma. In contrast, CQ promoted tumour development in the earlier so-called dysplastic stage, clearly illustrating the dual role of autophagy in tumour formation (see section on mechanisms of action) . Finally, Maes et al  reported that either a dose of 50 mg/kg or a dose of 100 mg/kg of CQ can reduce tumour growth and cell proliferation, dependent on the cell type. Of note, this study showed that CQ not only inhibits autophagy but also affects the tumour microenvironment and tumour vasculature. The exact working mechanisms will be clarified in the section on mechanisms of action.
Some studies noted that the efficacy of CQ application in anti-cancer therapy depends on the tumour type that is being treated and suggested that the autophagy dependency of tumour cells might play a role [27, 28]. For example, tumour growth was significantly reduced in an MDAMB231 xenograft mouse model, but not in an MCF-7 xenograft mouse model, while both models showed signs of autophagy inhibition after CQ treatment . A similar observation can be made when comparing CQ efficacy in pancreatic cancer mouse models and a lung cancer mouse model: CQ significantly slowed down tumour growth and increased survival in the first, but not in the latter . Another study by Hiraki et al  investigated the effects of CQ in various in vivo cancer models and demonstrated that CQ is more effective in connective tissue-rich Bashford and Brown–Pearce tumours than in Ehrlich, Yoshida and MH134 tumours.
A lack of efficacy in certain tumour models could potentially be explained by a study performed by Pellegrini et al exploring the effects of CQ under acidic conditions, which mimics the tumour environment. CQ bi-protonation under those conditions could impede cytotoxicity, because the cellular uptake of CQ is reduced. This observation highlights a possible limitation of CQ in anti-cancer therapy. However, the sensitivity of tumour cells might be restored using tumour pH-modulating agents . Ironically, hypoxic cells that can increase acidification of the extracellular space through anaerobe glycolysis are often more autophagy-dependent and, therefore, more sensitive to CQ treatment, as shown by in vitro studies .
A limited amount of studies reported potential detrimental effects of CQ and HCQ in in vivo cancer models. First, CQ pre-treatment of rats one week before a subcutaneous injection with mammary adenocarcinoma and follow-up treatment for 18 days following this event significantly enhanced tumour weight and volume in these rats . Second, in a 1966 paper, very low CQ doses (0.2 mg/2 days) led to a more infiltrative morphological pattern of the advancing margin of subcutaneously transplanted mammary carcinoma in mice . Third, malignant tumour growth and metastasis of Ras(V12) cells is observed in transgenic drosophila models after CQ administration . Importantly, HCQ promoted tumour growth in Ras-driven pancreatic tumours developing without p53(KrasG12D/+p53–/–) . Collectively, these results on a possible detrimental effect of (H)CQ emphasise the importance of the specific tumour setting and tumour characteristics when targeting autophagy (see section on mechanisms of action) [35, 36].
Table 2 summarises the information from articles that studied the effect of CQ (n = 46) or HCQ (n = 5) in vivo in combination with other therapies. A more interesting and still under-explored treatment approach for a complex disease such as cancer is to combine various anti-cancer agents acting at different levels in the tumour cells and microenvironment . Interestingly, CQ and HCQ have already been tested in combination with over 40 other drugs in preclinical cancer research. Both CQ and HCQ can effectively increase the efficacy of various anti-cancer drugs, which is further explained in the section on mechanisms of action. Therapies used in combination with CQ or HCQ include chemotherapeutic drugs, tyrosine kinase inhibitors, various monoclonal antibodies, hormone therapies and radiotherapy (Table 2).
Overview of in vivo research combining known anti-cancer agents with either CQ or HCQ.
|Reference||(H)CQ||Intervention||Animal model||Tumour type||Therapeutic effect of combination therapy|
|Golden et al ||CQ||Temozolomide (TMZ)||4- to 6-week-old male athymic nu/nu mice||U87MG glioma cells||Higher levels of the proapoptotic protein C/EBP homologous protein/growth arrest- and DNA damage-inducible gene 153 (CHOP/GADD-153)|
|Zanotto-Filho et al ||CQ||TMZ|
|8-week-old male wistar rats||C6 brain cells||Autophagy inhibition and significantly reduced tumour growth|
|Gaudin et al ||CQ||Cyclophosphamide|
|Golden Syrian hamster||Melanoma and plasmacytoma||Sensitisation to cyclophosphamide|
|Lefort et al ||CQ||Cyclophosphamide|
|6-week-old female Swiss nude mice||MDA-MB-231 human breast cancer cells||Significant tumour growth inhibition and reduction of lung metastases|
|Amaravadi et al ||CQ||Cyclophosphamide||8-to-10-week-old C57BL/6 ×129F1 mice||Myc/p53ERTAM lymphomas||Tumour growth inhibition and significant delay of tumour recurrence|
|Yu et al ||CQ||Cisplatin||4-to-6-week-old female BALB/c nu/nu mice||EC109/CDDP human oesophageal cells||Significantly lower tumour growth rate|
|Zhang et al ||CQ||Cisplatin||8-week-old female BALB/c mice||SGC7901 human gastric cancer cells||Significantly reduced tumour volume and weight|
|Zhao et al ||CQ||Cisplatin||5-to-6-week-old BALB/c nude mice||FaDu human hypopharyngeal cells||Prolonged survival|
|Ding et al ||CQ||Oxaliplatin||4-week-old male athymic BALB/c nude mice||Huh7 hepatocarcinoma cells||Significantly reduced tumour volume|
|Selvakumaran et al ||CQ||Oxaliplatin|
|8-to-10-week-old female C.B.17 SCID mice||HT29 human colon carcinoma cells||Significant tumour growth delay|
|Liang et al ||CQ||Carboplatin||immunodeficient SCID-Beige mice||SUM159 cells breast cancer cells (orthotopic)||Significantly reduced tumour growth, decreased mitochondrial metabolic activity, decreased cell viability and increased levels of LC3b-II and p62|
|Balic et al ||CQ||Gemcitabine||Immuno-compromised mice||patient- derived PDAC tumour tissues||Effective tumour elimination and improved overall survival|
|Shoemaker et al ||CQ||5-FU||Young adult female C3H mice||C3HBA mammary carcinoma||Significantly reduced tumour size|
|Guo et al ||CQ||5-FU||5-week-old male athymic BALB/c nu/nu mice||SMMC-7721 hepatocarcinoma cells||Significantly reduced tumour volume and weight and significantly higher levels of apoptosis|
|Sasaki et al ||CQ||5-FU||6-week-old female BALB/c mice||Colon26 colon cancer cells||Significantly increased inhibition of tumour growth and increased number of apoptotic cells and proapoptotic protein expression levels|
|Shoemaker et al ||CQ||5-FU|
|Adult female C3H/He mice||C3HBA breast cancer cells||Significant tumour reduction|
|Xiong et al ||CQ||Daunorubicin||Female DBA/2 mice on a folate-deficient diet||L1210JF leukaemia cells||No effect|
|Arnold et al ||CQ||Etoposide||Female CBA/Ca mice||TLX5 murine ascitic tumour cells||Significant improvement in increased life span|
|Cook et al ||HCQ||Tamoxifen and faslodex||5-week-old, intact, athymic nude mice||Tamoxifen-resistant MCF7-RR and faslodex-resistant /Tamoxifen cross-resistant LCC9 ER+ breast cancer cells||Significantly reduced tumour size and tumour wet weight with HCQ and tamoxifen, no effect with faslodex and HCQ|
|Loehberg et al ||CQ||Everolimus||4-to-6-week-old, female NMRI nu/nu mice||MCF7 breast cancer cells||Significant tumour suppression|
|Seront et al ||CQ||Rapamycin||8-week–old female NMRI nude mice||MDA-MB-231 and MCF-7 breast cancer cells||Tumour growth reduction in mice implanted with large, hypoxic mammary tumours (not in smaller tumours)|
|Bray et al ||CQ||Temsirolimus||nude mice||RCC4 renal carcinoma cells||Significantly reduced tumour growth|
|Kaneko et al ||CQ||Temsirolimus||4-to-6-week-old BALB/c nu/nu and BALB/c mice||CaR-1, HT-29, colon26 colon cancer cells||Significantly reduced tumour growth|
|Xie et al ||HCQ||Temsirolimus||6-week-old male nude NCr Nu-M mice||UACC903 melanoma cells||Significantly tumour suppression and slower tumour growth|
|Rao et al ||CQ||Panobinostat||NOD/SCID mice||MB-231-luciferase mammary cells||Slight additional decrease in tumour growth as compared to CQ or Panobinostat monotherapy, but significant increase in survival time|
|Carew et al ||CQ||Vorinostat||Female nude BALB/c mice||HCT8 colon cancer cells||Significantly enhanced tumour reduction|
|Ding et al ||CQ||Bortezomib||6-to-8-week-old female BALB/c mice||HCT116 colon cancer cells||Significant inhibition of tumour growth and higher levels of apoptosis|
|Hui et al ||CQ||Bortezomib||nude mice||MHCC-97H and Huh-7 hepatocarcinoma tissues||Significantly reduced tumour growth and increased apoptosis|
|Tang et al ||CQ||Gefitinib||6-week-old male BALB/c nude mice||PC-9/wt and PC-9/gefB4 lung cancer cells||Significantly reduced tumour growth|
|Dragowska et al ||HCQ||Gefitinib||female Rag2M immune-compromised mice||JIMT-1 breast cancer cells||58% tumour reduction|
|Bokobza et al ||CQ||Gefitinib|
(+ Akt inhibitor)
|BALB/c female nude mice||HCC-827 lung cancer cells||Significantly inhibited tumour growth compared to the control, addition of Akt inhibitor or chloroquine to gefitinib increased anti-tumour effects, but was not found to be significant.|
|Zou et al ||HCQ||Erlotinib||5-to-6-week-old athymic nude mice||H358 or H460 human NSCLC cells||Significant sensitisation to erlotinib therapy|
|Bellodi et al ||CQ||Imatinib||Sub-lethally irradiated C3H/HeJ mice||MigRI GFP-LC3b–transduced 32D-p210BCR/ABL cells||Significant sensitisation to imatinib therapy|
|Abdel-Aziz et al ||CQ||Sunitinib||Female Swiss albino mice||Ehrlich ascites carcinoma cells||Significantly reduced tumour growth and weight|
|Shimizu et al ||CQ||Sorafenib||BALB/c nude mice||Huh7 hepato-carcinoma cells||Significantly suppressed tumour growth|
|Shi et al ||CQ||Sorafenib||Male athymic BALB/c nude mice||MHCC97-L hepatocellular cells||Significantly reduced tumour growth and increased apoptosis|
|Ji et al ||CQ||Crizotinib||6- to 7-week-old female CD-1 nude mice||crizotinib-resistant H3122CR-1 lung cancer cells||Sensitisation of drug resistant lung cancer cells to crizotinib|
|You et al ||HCQ||Crizotinib||5-to-6-week-old female athymic BALB/c nude mice||SPC-A1 human lung cancer cells||Significantly reduced tumour growth and increased apoptosis|
|Mitou et al ||CQ||Crizotinib||6-week-old female NOD-SCID mice||Karpas-299 lymphoma cells||Significantly reduced tumour growth and increased apoptosis|
|Shen et al ||CQ||Vandetanib||6-to-8-week-old female BALB/c nude mice||U251 glioblastoma cells||Significantly reduced tumour growth and increased apoptosis|
|Hu et al ||CQ||Bevacizumab||6-to-8-week-old female BALB/c nu/nu mice||1) GBM39 primary glioma cells|
2) Subcutaneous U87MG glioma cells
3) G55 glioma cells
4) patient-specimen derived SF8244 cells
|Significantly suppressed GBM39, U87MG, G55, and patient specimen-derived SF8244 tumour growth|
|Selvakumaran et al ||CQ||Bevacizumab|
|8-to-10-week-old female C.B.17 SCID mice||HT29 human colon carcinoma cells||Significantly delayed tumour growth|
|Cufi et al ||CQ||Trastuzumab||4-to-5-week-old female athymic nude mice||JIMT-1 breast cancer cells||Significantly reduced tumour growth and increased Bax/Bcl-2 ratio|
|Gaudin et al ||CQ||Radiotherapy||Golden Syrian hamster||Melanoma and plasma cytoma||Increased sensitivity of melanoma and plasma cytoma tumour cells to X-rays|
|Ratikan et al ||CQ||Radiotherapy||6-week-old female H-2 3H/Sed//Kam and H-2 Rag2-/-, gamma c -/-mice||MCaK breast cancer cells||Significantly higher cure rate, delayed tumour growth and enhanced immunogenicity|
|Wei et al ||CQ||PDT||NOD/SCID mice||PROM1/CD133+ colorectal cancer stem cells||Restoration of sensitivity to PDT|
|Liang et al ||CQ||HDIL-2||8-to-10-week-old female C57BL/6 (B6, H-2b) mice||luciferase-labeled mouse MC38 colorectal cancer cells||Significantly reduced tumour growth and prolonged survival time|
|Thomas et al ||CQ||Nelfinavir|
|Athymic mice||MDA-MB-468 and MCF-7 breast cancer cells||Triple-drug treatment displayed obvious anti-cancer|
effects in both TNBC (MDA-MB-468) and non-TNBC (MCF-7) xenograft (=proof of principle study, more extensive in vivo experiments needed)
|Harhaji-Trajkovic et al ||CQ||Caloric restriction||5-to-6-week-old female C57BL/6 mice||B16 melanoma cells||Combination of CQ and caloric restriction almost completely abolished B16 melanoma growth|
|Thomas et al ||CQ||Hyperthermia||male white Ajax mice||C-1300 murine neuroblastoma||! Increased tumour growth and metastasis|
|Gao et al ||CQ||TACE||Adult New Zealand White rabbits||VX2 liver tumours||Significantly reduced tumour volume and growth rate|
Abbreviations: CQ (chloroquine), HCQ (hydroxychloroquine), SCID (severe combined immunodeficiency mice), PDAC (pancreatic ductal adenocarcinoma), 5-FU (5-fluorouracil) NOD (non-obese diabetic), wt (wild-type), PDT (photodynamic therapy), HDIL-2 (high-dose interleukin-2), TACE (transcatheter arterial chemoembolisation)Go to:
Numerous clinical trials in which either CQ or HCQ is being used to treat patients with a range of cancer types are registered in clinical trial databases. In clinical trials, these drugs are most often administered in combination with other anti-cancer agents. More information on the registered clinical trials is provided in Tables 3 and and4,4, for CQ and HCQ, respectively. Few trials have been completed. Therefore, limited published data are available on the safety and therapeutic efficacy of these antimalarial drugs in cancer. A schematic overview of the published clinical trial data of CQ and HCQ can be found in Tables 5 and and6,6, respectively.
Information on clinical trials investigating CQ use in cancer (Source: ClinicalTrials.gov).
|ClinicalTrials.gov ID||Type of cancer||Intervention||Study Phase||Location||Status||First received||Last verified|
(+ conventional treatment)
|Phase 3||Mexico||Completed||Sept 2005||Nov 2009|
|Phase 2||US||Completed, has results||Sept 2011||June 2016|
|Not provided||US||Completed||Nov 2012||Apr 2015|
|Phase 1||Switzerland||Completed||Jan 2013||Sept 2015|
|Phase 2||Mexico||Terminated||June 2013||July 2013|
|NCT01469455||Local metastatic melanoma||CQ,|
|Phase 1||France||Completed||Oct 2011||June 2016|
|NCT01023477||Ductal carcinoma in situ||CQ|
(Procedure: breast biopsy)
|Phase 1 – 2||US||Ongoing||Dec 2009||Sept 2016|
|NCT00969306||Small cell lung cancer||CQ||Phase 1||The Netherlands||Recruiting||Aug 2009||Feb 2016|
|Phase 2||US||Recruiting||Sept 2011||Sept 2016|
|NCT01575782||Small cell lung cancer||CQ,|
|Phase 1||The Netherlands||Recruiting||Apr 2012||Sept 2016|
|NCT02071537||Advanced solid tumours||CQ,|
|Phase 1||US||Recruiting||Feb 2014||Dec 2015|
|NCT02333890||Breast cancer||CQ (and placebo)|
(prior to surgery)
|Phase 2||Canada||Recruiting||Jan 2015||Nov 2016|
|Phase 2||Mexico||Recruiting||Feb 2015||Aug 2015|
|Phase 1 – 2||The Netherlands||Recruiting||June 2015||Nov 2015|
|Phase 1||The Netherlands||Recruiting||Feb 2015||Aug 2016|
Astrocytoma (Grade IV)
|Phase 2||Not provided||Not yet recruiting||Apr 2015||Apr 2016|
|NCT03243461||Glioblastoma WHO Grade IV, Diffuse Mid-line Glioma Histone 3 K27M, WHO Grade IV Anaplastic Astrocytoma WHO Grade III, Diffuse Intrinsic Pontine Glioma, Gliomatosis Cerebri||Radiochemotherapy with Temozolomide, Valproic Acid or Chloroquine||Phase 3||Germany||Not yet recruiting||Aug 2017||Oct 2017|
Information on clinical trials investigating HCQ use in cancer (Source: ClinicalTrials.gov).
|ClinicalTrials.gov ID||Type of cancer||Intervention||Study Phase||Location||Status||First received||Last verified|
|Phase 1 – 2||US||Terminated, has results||Oct 2008||Nov 2013|
|Phase 2||US||Terminated, has results||Nov 2008||Sept 2013|
|Phase 1 – 2||US||Terminated, has results||Aug 2008||Sept 2013|
|NCT01026844||Non-small cell lung cancer||HCQ,|
|Phase 1||US||Terminated, has results||Dec 2009||June 2013|
|NCT01842594||Soft tissue sarcoma||HCQ,|
|Phase 2||Taiwan||Terminated, has results||Dec 2012||Oct 2015|
|NCT01144169||Renal cell carcinoma||HCQ|
(prior to surgery)
|Phase 1||US||Terminated||June 2010||Oct 2016|
unspecified adult solid tumour
|Phase 1||US||Terminated||Aug 2011||Feb 2015|
|NCT00771056||B-cell chronic lymphocytic leukaemia||HCQ||Phase 2||US||Terminated||Oct 2008||Aug 2016|
|NCT00714181||Unspecified adult solid tumour||HCQ,|
|Phase 1||US||Completed||July 2008||Feb 2016|
|Phase 0||US||Completed||July 2011||Feb 2013|
|NCT01634893||Refractory or relapsed solid tumours||HCQ,|
|Phase 1||US||Completed||July 2012||Mar 2016|
|Phase 2||US||Completed||Mar 2013||Mar 2016|
|Phase 2||US||Suspended||Oct 2009||Dec 2014|
|NCT00726596||Prostate cancer||HCQ||Phase 2||US||Ongoing||July 2008||Dec 2015|
|NCT00813423||Adult solid neoplasm||HCQ,|
|Phase 1||US||Ongoing||Dec 2008||Nov 2016|
|NCT00909831||Unspecified adult solid tumour||HCQ,|
|Phase 1||US||Ongoing||May 2009||Feb 2016|
|NCT00962845||Melanoma||HCQ (prior to surgery)||Phase 0||US||Ongoing||Aug 2009||July 2016|
|NCT00977470||Non-small cell lung cancer||HCQ,|
|Phase 2||US||Ongoing||Sept 2009||Sept 2016|
Gemcitabine (prior to surgery)
|Phase 1 – 2||US||Ongoing||May 2010||Jan 2015|
|NCT01273805||Pancreatic cancer||HCQ||Phase 2||US||Ongoing||Jan 2011||Jan 2016|
|NCT01480154||Advanced solid tumours, melanoma, prostate or kidney cancer||HCQ,|
Akt Inhibitor MK2206
|Phase 1||US||Ongoing||Nov 2011||Feb 2016|
|NCT01689987||Relapsed or refractory multiple myeloma||HCQ,|
|Phase 1||US||Ongoing||Sept 2012||Aug 2016|
|Phase 1||US||Ongoing||June 2013||July 2016|
|NCT02421575||Prostate cancer||HCQ (before prostatectomy or local therapy)||Phase 0||US||Ongoing||Dec 2014||July 2016|
Radiation: Proton or Photon
|Phase 2||US||Ongoing||July 2011||Sept 2016|
Short Course radiotherapy
|Phase 2||UK||Ongoing||May 2012||Nov 2016|
|NCT02470468||Stage IV non-small cell lung cancer||DCVAC,|
Standard of Care Chemotherapy
Immune enhancers (Interferon-α and HCQ)
|Phase 1 – 2||Czech Republic and Slovakia||Ongoing||June 2015||Nov 2016|
|NCT01023737||Malignant solid tumour||HCQ,|
|Phase 1||US||Recruiting||July 2009||Sept 2016|
|Phase 1 – 2||US||Recruiting||Sept 2010||Sept 2016|
|Phase 1||US||Recruiting||Dec 2010||Nov 2016|
|NCT01510119||Renal cell carcinoma||HCQ,|
|Phase 1 – 2||US||Recruiting||Jan 2012||Dec 2015|
|NCT01506973||Advanced and metastatic adenocarcinoma||HCQ,|
|Phase 1 – 2||US||Recruiting||Jan 2012||Sept 2016|
|NCT01550367||Metastatic renal cell carcinoma||HCQ,|
|Phase 1 – 2||US||Recruiting||Feb 2012||May 2015|
|NCT01649947||Non-small cell lung cancer||HCQ,|
|Phase 2||US||Recruiting||July 2012||July 2016|
|Phase 2||US||Recruiting||Oct 2013||Dec 2015|
|Phase 1 – 2||US||Recruiting||Dec 2013||Sept 2016|
|NCT02232243||Solid tumour||HCQ (prior to surgery)||Phase 1||US||Recruiting||Sept 2014||Oct 2016|
|NCT02257424||Advanced BRAF mutant melanoma||HCQ,|
|Phase 1 – 2||US||Recruiting||Oct 2014||June 2016|
|Phase 2||US||Recruiting||Dec 2014||Sept 2016|
|NCT02414776||Oestrogen receptor positive breast cancer||HCQ,|
|Phase 1 (1b/2)||US||Recruiting||Jan 2015||Apr 2015|
|NCT02631252||Acute myeloid leukaemia||HCQ,|
|Phase 1||US||Not yet recruiting||Dec 2015||Dec 2015|
|NCT02722369||Small cell lung cancer||HCQ,|
|Phase 2||Not provided||Not yet recruiting||Mar 2016||Nov 2016|
|NCT00486603||Brain and central nervous system tumours||HCQ,|
|Phase 1 – 2||US||Unknown||June 2007||May 2012|
|NCT00568880||Multiple myeloma and plasma cell neoplasms||HCQ,|
|Phase 3||US||Unknown||Dec 2007||July 2009|
|NCT00809237||Non-small cell lung cancer||HCQ,|
|Phase 1 – 2||Singapore||Unknown||Dec 2008||Dec 2013|
|NCT01227135||Chronic myeloid leukaemia||HCQ,|
|Phase 2||UK||Unknown||Oct 2010||Nov 2011|
|NCT01292408||Breast cancer||HCQ||Phase 2||The Netherlands||Unknown||Dec 2010||Jan 2012|
Abbreviations: FOLFOX6 (folinic acid – 5- fluorouracil – oxaliplatin), XELOX (capecitabine – oxaliplatin), IL-2 (interleukin-2), TACE (trans catheter arterial chemoembolisation), DCVAC (dendritic-cell based immunotherapy)
Publications reporting clinical trial results on CQ use in cancer.
|Article||Tumour type||Phase||Intervention||CQ dose||# patients||Therapeutic response|
|Briceño et al ||Glioblastoma multiforme||Unknown||CQ + conventional cancer treatment||150 mg/day||18 (9 CQ + 9 control)||Positive|
|Sotelo et al ||Glioblastoma multiforme||Phase 3||CQ + conventional cancer treatment||150 mg/day||30 (15 CQ + 15 control)||Partial|
|Briceño et al ||Glioblastoma multiforme||Retrospective study based on patient data||CQ + conventional cancer treatment||150 mg/day||123 (41 CQ + 82 control)||Positive|
|Rojas-Puentes et al ||Brain metastases||Phase 2||CQ + radiotherapy||150 mg/day||73 (39 CQ + 34 control)||Partial|
|Eldredge et al ||Brain metastases||Unknown||CQ + radiotherapy||250 mg/day||20 (all CQ, no control)||Partial|
|Montanari et al ||Relapsed and refractory multiple myeloma||Phase 1 – 2||CQ + bortezomib + cyclophosphamide||500 mg/day||8 (all CQ, no control)||Partial|
|Kyle et al ||Multiple myeloma||Unknown||CQ + prednisone + cyclophosphamide + caffeine||2x 250 mg/day||38 (18 CQ + 20 control)||Absent|
Publications reporting clinical trial results on HCQ use in cancer.
|Article||Tumour type||Phase||Intervention||HCQ dose||# patients||Therapeutic response|
|Rangwala et al ||Advanced solid tumours and melanoma||Phase 1||HCQ + temsirolimus||RD: 2x 600 mg/day||39 (all HCQ, no control)||Partial|
|Rangwala et al ||Advanced solid tumours and melanoma||Phase 1||HCQ + temozolomide||RD: 2x 600 mg/day||40 (all HCQ, no control)||Partial|
|Mahalingam et al ||Advanced solid tumours||Phase 1||HCQ + vorinostat||MTD: 600 mg/day||27 (all HCQ, no control)||Partial|
|Chi et al ||Stage IV solid tumours||Pilot||HCQ + sirolimus + chemotherapy||400 mg/day||25 (all HCQ, no control)||Partial|
|Rosenfeld et al ||GBM||Phase 1–2||HCQ + radiotherapy + temozolomide||MTD: 600 mg/day||92 (all HCQ, no control)||Absent|
|Goldberg et al ||Advanced NSCLC||Phase 1||HCQ + erlotinib||RD: 1000 mg/day||27 (all HCQ, no control)||Partial|
|Vogl et al ||Relapsed and refractory multiple myeloma||Phase 1||HCQ + bortezomib||RD: 2x 600 mg/day||25 (all HCQ, no control)||Partial|
|Boone et al ||Pancreatic adenocarcinoma||Phase 1–2||HCQ + gemcitabine||RD: 1200 mg/day||35 (all HCQ, no control)||Partial|
|Wolpin et al ||Metastatic pancreatic adenocarcinoma||Phase 2||HCQ||400 and 600 mg/day||20 (all HCQ, no control)||Absent|
|Chi et al ||Sarcoma||Phase 2||HCQ + sirolimus||2x 200 mg/day||10 (all HCQ, no control)||Absent, study was closed prematurely|
Abbreviations: MTD (maximal tolerated dose), RD (recommended dose), NSCLC (non-small cell lung cancer)
In the next section, the clinical effects of CQ and HCQ will be discussed separately because important differences can be observed in toxicity and efficacy of both drugs.
Glioma and brain metastases
In May 1998, one of the first clinical trials on CQ use in cancer was started, which was an open, prospective, randomised controlled study with 18 glioblastoma multiforme (GBM) patients . The test group consisted of nine patients who received 150 mg CQ daily after resection of the lesion, in addition to radiotherapy (total dose of 6000 Gy) and four cycles of carmustine-chemotherapy every six weeks (200 mg/m2), while the nine patients in the control group received placebo instead of CQ. In the abstract of this study, the authors reported that adjuvant CQ administration significantly enhanced patient survival [33 ± 5 months for CQ-treated patients and 11 ± 2 months for controls (p < 0.0002)]. Due to some inconsistencies in the report, the calculation of the mean survival in the CQ-treated group is unclear, but the Kaplan Meier analysis remains significant. A higher seizure frequency was observed in the CQ-treated group and could not be explained. However, standard antiepileptic treatment was reported to easily suppress these seizures. The same group of researchers started a similar randomised, double blind, placebo-controlled study in October 2000 . In this second study, 15 GBM patients received 150 mg CQ each day for 12 months after surgery in combination with their conventional anti-cancer therapy, four cycles of carmustine-chemotherapy every five weeks (200 mg/m2) and a total radiation dose of 60 Gy; the other 15 patients received adjuvant placebo treatment. A median survival time of 24 months was observed in the CQ-treated group, as compared with 11 months in the control group. In addition, the hazard ratio for death was approximately half as large in the patients receiving CQ though this was not statistically significant (hazard ratio: 0.52, [95% CI 0.21–1.26, p = 0.139]). No important adverse effects were noted in this trial. The small sample size is an important limitation in both studies, and larger clinical trials are needed to confirm the efficacy of CQ in GBM therapy [39, 40]. In a retrospective study, the same research group looked at data collected over five years from 41 GBM patients in Mexico who received adjuvant CQ therapy and did not participate in the previously mentioned clinical trials . The mean survival time of these CQ-treated patients was significantly longer compared with a control group of 82 glioblastoma patients [25 ± 3.4 months and 11.4 ± 1.3 months after surgery respectively (p = 0.000)].
After the observation of promising outcomes in five recurrent GBM patients treated with 250 mg CQ a day and reirradiation for 20 months , a phase-2 clinical trial tested the effects of CQ as a radio-sensitising agent in patients with brain metastases . In this trial, 39 patients were administered whole-brain irradiation (30 Gy in 10 fractions over two weeks) in combination with a daily dose of 150 mg CQ for four weeks, while 34 patients received placebo instead of CQ in addition to the same radiation treatment. The overall response rate or OS did not improve after CQ administration. However, the progression-free survival of brain metastases rate was increased (CQ-treated group: 83.9% [95% CI 69.4–98.4] and control group: 55.1% [95% CI 33.6–77.6] (at one year), relative risk: 0.31 [95% CI 0.1–0.9, p = 0.046]). The absence of adverse effects and the improved local control of brain metastases indicate that CQ might be a useful addition to whole brain irradiation in patients with brain metastases. In a prospective, single-cohort study of 20 patients with brain metastases from solid tumours, 250 mg CQ daily was administered for five weeks in combination with whole-brain irradiation . The intracranial response rate corresponded to an objective clinical response of 93% after three months of whole-brain irradiation, there was a slight, positive trend in OS (median OS of 5.7 months, compared with 4.2 months for patients in class II estimated by the radiation therapy oncology group recursive partitioning analysis), and no adverse reactions were detected. Finally, two case reports mentioned unusual skin reactions after concomitant use of CQ and radiation, illustrating the radio-sensitising effect of CQ [45, 46].
In a paediatric patient with a recurrent BRAF V600E mutant brainstem ganglioglioma, tumour growth was blocked and vemurafenib sensitivity restored following treatment with 150 mg CQ daily for at least 30 months [47, 48]. The same research group reported in vitro and ex vivo data showing that autophagy inhibition was able to improve the response to BRAF inhibition in resistant tumour cells . Next, CQ was administered to two patients with acquired resistance to BRAF inhibition. The first patient was treated with standard doses of vemurafenib plus 250 mg daily of CQ during focal radiation of large primary lesions. Vemurafenib was continued and the CQ dose was increased to 500 mg daily after completion of radiation. A rapid favourable clinical response to the combination therapy was observed in as little as six weeks and was maintained for seven months, at which point the patient had to stop therapy for unrelated medical issues. The second patient was treated with 500 mg CQ daily in combination with standard dosing of vemurafenib. Acquired resistance to vemurafenib was overcome within four weeks of the addition of CQ and clinical improvement could be observed, which was maintained for two and a half months. However, therapy had to be stopped and the family chose to pursue palliative therapy afterwards.
Eleven patients with relapsed and refractory multiple myeloma were enrolled and treated with 500 mg CQ daily (on days 1–14 and 22–35) in addition to bortezomib and cyclophosphamide (administered orally twice daily) in a phase-2 clinical trial . Of these eleven patients, only eight patients were evaluable. CQ was able to partially restore the bortezomib sensitivity: three patients had a partial response, one had stable disease and four had progression as best responses.
The adjuvant therapeutic effect of 250 mg CQ twice daily in combination with cyclophosphamide and prednisone was tested for a period of ten days in 38 myeloma patients . Twenty patients received cyclophosphamide and prednisone, while the other 18 patients received extra treatment with CQ and caffeine, but no additional response was observed in the CQ-treated patient group.
The effect of HCQ and temsirolimus combination therapy was tested in 27 patients with advanced solid cancer during a phase-1 dose-escalating study and subsequently in 13 patients with metastatic melanoma at the phase-2 recommended dose . No patient experienced an objective response but 19 out of the 27 phase-1 patients (73%) and 9 out of 13 melanoma patients (69%) had stable disease. In patients with stable disease, HCQ addition was shown to produce metabolic stress in the tumours. Inhibition of autophagy (see section on mechanisms of action), measured by counting the number of autophagic vacuoles per cell in tumour tissues and peripheral blood mononuclear cells of patients, was only noted in patients receiving at least 1200 mg HCQ daily. This study recommends an adjuvant HCQ dose of 600 mg, twice daily.
Next, the combinatory effect of HCQ and temozolomide was investigated in 40 cancer patients with advanced solid tumours and melanoma, and the recommended dose of 600 mg twice daily was confirmed . HCQ was shown to successfully inhibit autophagy, as evidenced by the significant accumulation of autophagic vacuoles in peripheral blood mononuclear cells (mean autophagic vacuole counts: 2.19 at baseline, 2.45 after HCQ treatment, 3.84 after treatment with HCQ plus TMZ [difference between HCQ plus TMZ and baseline: p = 0.0007, difference between HCQ plus TMZ and HCQ only: p = 0.0034]).
The safety and preliminary efficacy of HCQ and vorinostat combination treatment was tested during a phase-1 study in 27 patients with advanced solid tumours . In this study, the maximum-tolerated HCQ dose was set at 600 mg daily in combination with 400-mg vorinostat. A confirmed durable partial response was observed in a renal cell carcinoma patient, and prolonged stable disease was seen in two colorectal cancer patients. In contrast to the previous study, autophagy was not significantly affected.
Finally, in a pilot retrospective study, 25 stage-IV cancer patients (various types) who had no clinical response to maximally tolerated chemotherapy and to first-line metronomic chemotherapy were treated with sirolimus (2 mg/day) and the autophagy inhibitor HCQ (400 mg/day) in addition to their current metronomic chemotherapy for at least three months. The therapy was reported to be relatively safe, and the overall response rate was 40%, with an 84% disease control rate . However, this was a retrospective analysis requiring cautious interpretation.
The efficacy and safety of HCQ was studied in combination with radiotherapy and temozolomide in 92 GBM patients during a phase-1–2 study . This study indicated a maximum tolerated dose (MTD) of 600 mg HCQ a day in this therapeutic setting. OS did not seem to be affected in comparison with the temozolomide arm of the trial reported by Stupp , and autophagy was not found to be consistently inhibited in all patients.
The combination of HCQ with erlotinib can be used safely in daily doses of 150 mg erlotinib and 1000 mg HCQ, as determined by a phase-1 study in 27 patients with advanced non-small cell lung cancer (NSCLC) . Of the 19 patients who remained in the study, one had a partial response and four had stable disease as best response. Subsequent ophthalmic surveillance on seven trial participants who had taken HCQ for a duration longer than six months showed that retinal toxicity occurred in two patients after 11 and 17 months of exposure .
This highlights the importance of retinal toxicity monitoring (via high-resolution spectral-domain optical coherence tomography, fundus auto fluorescence imaging, Humphrey visual field testing and multifocal electroretinography) during clinical trials with HCQ.
During a phase-1 study, the safety of the combination of HCQ and bortezomib was explored in 25 patients with relapsed or refractory myeloma . A dose of 600 mg HCQ twice daily was reported to be safe and tolerable in combination with standard doses of bortezomib. The increase in the number of autophagic vacuoles was not significantly associated with clinical response or HCQ exposure. Of 22 evaluable patients, three (14%) had very good partial responses, three (14%) had minor responses, ten (45%) had stable disease for at least one cycle and six (27%) had immediate progression.
The safety of the combination of pre-operative HCQ (1200 mg daily) and gemcitabine administration was demonstrated in 35 patients with pancreatic adenocarcinoma in a phase-1–2 trial . This study reported promising clinical response markers (e.g. CA 19–9 biomarker and R0 resection rate). An exploratory analysis showed significantly improved disease-free survival and OS (15.03 versus 6.9 months and 34.83 versus 10.83 months, respectively) in patients for whom autophagy was sufficiently inhibited (n = 8) (at least 51% increase in the autophagy marker LC3B-II in peripheral blood mononuclear cells) compared with other patients (n = 9).
Next, a phase-2 study investigated the safety and efficacy of HCQ monotherapy with either 400 or 600 mg two times a day in 20 patients with previously treated metastatic pancreatic cancer, but no significant differences were observed between groups . In addition, inhibition of autophagy could not be achieved consistently, as shown by LC3B-II analysis in the lymphocytes of patients, and the two-month progression-free survival rate was only 10%.
The combination of 1 mg sirolimus and 200 mg HCQ twice daily for two weeks was tested in ten sarcoma patients who had failed first-line treatment . This study started from the hypothesis that there is metabolic symbiotic relationship between cancer-associated fibroblasts (CAFs) and sarcoma cells (see mechanisms of action). The study showed that this relationship might be altered by treatment with sirolimus and HCQ as glycolysis was inhibited within the tumours. Based on FDG PET response criteria, two weeks after treatment initiation, six patients showed partial response, three had stable disease and one had progressive disease. However, most patients discontinued treatment before the initially planned eight-week response assessment, for disease progression.Go to:
Mechanism of action
Multiple hypotheses have been proposed on how CQ and HCQ exert their anti-cancer activity. Most studies reported the direct action of these drugs on cancer cells, but more recent studies have also mentioned important effects of CQ and HCQ on the tumour microenvironment. Based on preclinical studies, it is safe to say that CQ and HCQ have multiple mechanisms of action that might complement each other.
The most relevant and evidence-based mechanisms of action of CQ and HCQ in anti-cancer treatment will be briefly explained in the next section. The benefits of combining these antimalarial drugs with existing anti-cancer treatments will also be described. In the final section, the variation in sensitivity of cancer patients to CQ and HCQ therapy will be clarified.
Direct anti-tumour effects
The main and most studied anti-cancer effect of CQ and HCQ is the inhibition of autophagy, but other preclinically proven anti-cancer activities of the antimalarial agents include influencing the TLR9/nuclear factor kappa B (NF-κB) signalling pathway, the CXCL12/CXCR4 signalling pathway and the p53 pathway.
Autophagy literally means ‘self-eating’. It is a process in which a cell destroys old or defective cellular components, thereby releasing cellular building blocks including nucleotides, amino acids and fatty acids. Those degradation products can later be recycled by the cell to meet its metabolic needs. Autophagy is an essential intracellular process to ensure cell survival under stressful conditions (e.g. hypoxia, starvation and organelle damage). Different types of autophagy exist but, here, we will use the term to refer to macroautophagy. Autophagy is a complex multi-faceted process . One putative biomarker is the level of LC3B-II, an essential protein during autophagosome formation and the level of scaffolding protein p62 [or sequestosome 1 (SQSTM1)] [64, 65]. Autophagy has both pro-tumour and anti-tumour functions, which may be both stage and tissue-type specific.
In early carcinogenesis, autophagy has a tumour suppressive role since it has an important quality control function and protects the cell by sequestering and eliminating defective cellular components, such as damaged mitochondria, and by maintaining cellular homeostasis [66, 67]. In addition, several autophagic proteins can directly suppress tumour formation (e.g. Beclin-1, UVRAG and Bif-1) and autophagy has been shown to degrade tumour promoting proteins as well (e.g. p62/SQSTM1) . In line, deregulation of autophagy has been repeatedly associated with human cancers .
In contrast, autophagy can promote tumour growth in more advanced stages of cancer . Pro-survival autophagy is induced in response to a variety of stressful conditions including but not limited to, starvation, loss of proteostasis, organelle damage and hypoxia. Some anti-cancer treatments can also induce pro-survival autophagy. Autophagic properties such as nutrient recycling can support cancer cell survival. Moreover, key regulators of cell growth can be degraded and the DNA damage response can be suppressed through increased autophagy [66–68]. Therefore, inhibition of autophagy can be an interesting anti-cancer strategy when cancer cells start depending on autophagy for survival, a moment called the autophagic switch [64, 70].
CQ and HCQ inhibit the autophagic flux at a late stage (Figure 1): the fusion of the autophagosomes with the lysosomes and subsequent degradation of the autolysosome. Upon entering the lysosomes, CQ and HQ become protonated, which leads to their entrapment in acidic lysosomes and an increase in the lysosomal pH, which inhibits the lysosomal degradative enzymes . Loehberg et al  suggested that CQ might also modulate autophagy by modifying the PI3K/Akt/mTOR pathway.
Figure 1.Autophagic process. (1) Elongation of the phagophore and vesicle formation. (2) Fusion of the autophagosome and a lysosome. (3) Destruction of the engulfed cellular components by lysosomal hydrolases. CQ and HCQ inhibit autophagy through interference with the lysosomal acidification (Step 2).
In summary, autophagy plays a dual role in cancer and the success of autophagy inhibition, using the late stage inhibitors CQ and HCQ, depends on the timing and context. Autophagy is an interesting therapeutic target after the autophagic switch. However, the autophagy dependency of the tumour cells and any combinatory therapies can influence the sensitivity to autophagy inhibition, which will be discussed later.
Inhibition of the TLR9/nuclear factor kappa B signalling pathway
TLR9, a member of the Toll-like receptor family, is located in the endosomal compartment. This receptor recognises unmethylated single stranded DNA and is necessary for pathogen recognition and innate immune system activation. In cancer, expression and stimulation of TLR9 is linked with invasiveness, as shown in in vitro experiments [73–75]. Moreover, the expression levels of TLR9 are higher in hepatocellular carcinoma, oesophageal, lung, breast, gastric and prostate cancer cells as compared with adjacent noncancerous cells, and high expression is often linked with poor prognosis [73–76]. Because of this observation, it was suggested that TLR9 might be an appropriate anti-cancer target [73, 74, 76].
The TLR9-mediated activation of the NF-κB signalling pathway and the associated enhanced expression of matrix metalloproteinase-2 (MMP-2), MMP-7 and cyclo-oxygenase 2 mRNA, all factors associated with tumour progression and migration, can explain the role of TLR9 in cancer [73, 74]. At first, CQ was thought to inhibit this pathway by inhibiting endosomal acidification. However, CQ most likely modifies the structure of the nucleic acids responsible for TLR activation to prevent binding to TLRs . An in vitro study also showed that invasion of brain cancer cells is hypoxia-induced through upregulation of TLR9 expression, which could be significantly inhibited by CQ .
In contrast, low expression of TLR9 is reported to be associated with a poorer prognosis in patients with triple-negative breast cancer. CQ had a promising effect on tumour growth and invasiveness, independent of the TLR9 status in triple-negative breast cancer cells in vitro, but it did not reduce the growth of orthotopic triple-negative breast cancer tumours in vivo [79, 80].
Inhibition of CXCL12/CXCR4 signalling
The interaction between the CXCR4 chemokine receptor and its ligand CXCL12 plays a major role in chemotaxis and adhesion of cells, and secretion of growth factors. In recent years, research has shown an association between CXCL12/CXCR4 signalling and cancer progression [81, 82]. This interaction is said to influence the invasive phenotype of pancreatic cancer for example.
In 2012, a CXCR4 small molecule antagonist (NSC56612), structurally resembling CQ and HCQ, was identified through in silico modelling of this receptor . Next, CQ and HCQ were tested via in vitro assays, in which they were found to suppress pancreatic cancer cell proliferation [82, 83]. Mechanistic studies have shown that CQ, at least, partially inhibits CXCL12/CXCR4 signalling, as demonstrated via reduced phosphorylation of the extracellular signal-regulated kinase (ERK) and the signal transducer and activator of transcription 3 (STAT3). Interestingly, CQ and HCQ can induce CXCR4 internalisation in cancer stem cells, making these cells less sensitive to CXCL12 signals .
Furthermore, a study in a pancreatic cancer patient-derived xenograft model showed that CQ specifically targets highly aggressive cancer stem cells through inhibition of their self-renewal process. Thus, CQ could be useful to block cancer stem cell-metastasis and may be combined with other anti-cancer agents (e.g. gemcitabine) that target the bulk of the tumour .
Interference with the p53 pathway
The tumour suppressor protein p53 plays an essential role in maintaining an error-free genome and inducing cell death in case the damage is irretrievable. Therefore, it is a key protein in the prevention of tumour development .
Both in vitro and in vivo research has indicated that CQ can stabilise the p53 protein and activate the p53-dependent transcription of pro-apoptotic genes [17, 23, 24, 72, 84, 85]. Several hypotheses have been proposed to explain the underlying mechanism, but there is no definite answer yet. One of these hypotheses is that CQ intercalates in DNA, which leads to structural changes and thus induction of p53 [17, 85]. Moreover, the p53 activation by CQ might be mediated by the ataxia telangiectasia mutated protein, dependent on the cell type [17, 23, 24]
There is also some discussion about the relationship between the p53 status and the effects of autophagy inhibition on cancer development. Several studies report an accelerated tumour development when autophagy is inhibited in mice without p53 [35, 86, 87], but Yang et al  showed that that inhibition of autophagy could still have beneficial effect in p53 mutant tumours. Other studies confirmed that CQ exerts anti-cancer effects independent of the p53 pathway and the p53 status [88–90]. Synergy between the p53-dependent and -independent mechanisms of CQ is likely .
Recently, a p53-dependent mechanism was reported in which CQ induces tumour suppressor protein Par-4 secretion, triggering paracrine apoptosis of cancer cells and inhibition of tumour metastasis. This mechanism involves the CQ-dependent activation of p53 and the subsequent induction of Rab8b, which is necessary for transport of vesicles of Par-4 to the plasma membrane .
Moreover, CQ might prevent degradation of a p53-related protein, called Bcl homology-3-only protein p53 upregulated modulator of apoptosis (PUMA), as shown in mice studies. CQ increased the levels of PUMA, without affecting p53 in these studies [20, 92].
Other potential mechanisms of action
Additional mechanisms have been suggested, but they have not been studied to the same extent and will only be briefly described here.
In recent years, it has become clear that glutaminolysis plays an important role in metabolic processes associated with cancer cell proliferation and survival. Therefore, targeting glutaminolysis could provide novel approaches to improve cancer treatment . It was shown that CQ affects glutamate dehydrogenase activity [94–96], which could be a potential mechanism of action in anti-cancer treatment. The hypothesis of inhibiting metabolic processes using metformin and CQ is currently being tested in one clinical trial with patients with isocitrate dehydrogenase 1 and 2 (IDH1/2)-mutated chondrosarcoma, glioma and intrahepatic cholangiocarcinoma .
CQ and HCQ can activate caspase-3 and modulate the Bcl-2/Bax ratio inducing apoptosis in CLL, B-cell CLL and glioblastoma cells [17, 89, 98–100]. CQ-mediated cell-cycle-arrest and apoptosis was observed in breast cancer cells and was associated with a decrease in protein levels/activity of polo-like kinase 1 (Plk-1), ERK1/2 Akt and cell division cycle 25C (CDC25C). The same study described induction of caspase-3-mediated spindle abnormalities and down regulation of the mitochondrial transmembrane potential by CQ . A decreased lung cancer cell growth after low CQ concentrations was ascribed to an increased lysosomal volume and a phosphatidylcholine-specific phospholipase C involvement (PC-PLC). Higher CQ concentrations still induce apoptosis and necrosis, but likely via different processes .
Moreover, HCQ might affect acetylation status in the N-terminal lysines of histones H3 and H4, thus modulating cell growth and differentiation, as shown in human breast cancer cells .
In addition, CQ might directly affect Hedgehog signalling. Under normal conditions, this is a quiescent pathway, but activation can cause tumorigenesis and maintains cancer stem cells. Anti-cancer treatment options targeting this specific pathway have been explored, but this has yielded little results so far . One study suggested that CQ might modulate protein levels of the Hedgehog signalling pathway (smoothened, patched and GLI1 proteins) .
CQ can inhibit hypoxia-stimulated metastasis via modulation of hypoxia-inducible factor 1α (HIF-1α), vascular endothelial growth factor (VEGF), and epithelial mesenchymal transition (EMT) as shown in a cholangiocarcinoma cell line .
In triple-negative breast cancer, CQ was shown to eliminate cancer stem cells through reduction of the expression of Janus-activated kinase 2 and DNA methyl transferase 1  or through induction of mitochondrial dysfunction, subsequently causing oxidative DNA damage and impaired repair of double-stranded DNA breaks .
Of note, various studies showed growth inhibition of melanoma cells after CQ administration, but this inhibition was more pronounced in pigmented melanoma, which could be ascribed to CQ’s high affinity for melanin . There is also some contradictory evidence about a potential link between Burkitt’s lymphoma incidence and CQ administration [109, 110].
Modulation of tumour micro-environment
An increasing level of research is addressing the essential role of the immune system in cancer development. Activating the immune system against cancer cells is becoming a promising therapeutic approach , as immune cells have the ability to detect and destroy malignant cells .
Interestingly, autophagy and lysosomal function have been found to be involved in both innate and adaptive immunity . Therefore, inhibitors of these processes such as CQ and HCQ could potentially modulate the immune system and subsequently influence tumour development. However, lysosomal function and autophagy have a dual role in the anti-tumour immune response. Activation of these processes could both activate and impair the immune response, dependent on the circumstances . In addition, autophagy and lysosomal function affect the response of tumour cells to the immune system as well. For example, tumour cell autophagy can generate mediators that provoke an immune response via modulation of the tumour cell secretome and surface proteome, but it may also help tumour cells to escape the immune system [64, 66].
In general, the interaction between cancer cells and the immune system is complex and further research is warranted to determine when CQ or HCQ administration can lead to beneficial effects in the context of anti-tumour immunity . This is particularly important if CQ or HCQ would be considered for use in combination with immunomodulation anti-cancer therapies.
Normalisation of the tumour vasculature
The tumour vasculature, responsible for supplying the tumour with nutrients and oxygen, is an important component in the tumour micro-environment and plays an essential role in tumour cell metastasis . A first therapeutic approach is to destroy blood vessels in order to block the nutrient and oxygen supply to the tumour. However, accumulating evidence suggests that improving the highly abnormal tumour vessel structure, also called vessel normalisation, is preferred over anti-angiogenic therapy. The benefits of vessel normalisation include a decrease in tumour hypoxia, reduced cancer cell intravasation and metastasis, and an increase in chemotherapeutic drug delivery and response [114, 115].
A recent study showed that CQ normalises tumour vessels, independent of its autophagy inhibitory effect, through reduction of vessel density and improvement of cell alignment and formation of tight junctions. At the molecular level, CQ alters endosomal Notch1 trafficking and signalling in endothelial cells, hereby increasing the quiescent phenotype of the endothelial cells [26, 116]. Of note, systemic CQ administration has also been shown to reduce the vascular toxicity of the intratumorally administered, anti-tumour agent Transferrin-CRM107 in in vivo glioma models .
Disruption of the CAF—cancer cell interplay
The final interplay between the tumour and its microenvironment that may be influenced by CQ involves CAFs . Glutamine and caveolin-1 are key players in this autophagy-mediated interplay, in which CAFs and tumour cells support each other through glutamine production/secretion and autophagy stimulation. Interestingly, this interplay can be uncoupled through the autophagy inhibitory or lysosomotropic activity of CQ, but the exact mechanism should still be clarified [119, 120].
Synergism with approved anti-cancer drugs
Existing anti-cancer therapies often induce pro-survival autophagy in cancer cells, which is associated with therapeutic resistance. Because of their ability to inhibit autophagy, CQ and HCQ are able to sensitise tumour cells to chemotherapy and radiation. Therefore, these drugs are often tested in (pre)clinical research in combination with other anti-cancer therapies. Though, some caution is advised when concomitantly using these antimalarial drugs with other anti-cancer agents because autophagy can also be inhibited in normal cells, which causes unwanted toxicity (e.g. nephrotoxicity) .
CQ-mediated sensitisation to anti-cancer therapy has also been ascribed to autophagy-independent mechanisms. As mentioned earlier, chemotherapeutics can reach the tumour site more easily after tumour vessel normalisation [26, 116]. Moreover, CQ can prevent the entrapment of protonated chemotherapeutic drugs by buffering the extracellular tumour environment and intracellular acidic spaces . For example, CQ can reduce the endosomal sequestration of certain drugs by raising the endosomal pH and, thus, increase their efficacy (e.g. doxorubicin, daunorubicin and mitoxantrone) [122–124]. Vezmar et al [125, 126] suggested that CQ influences multidrug resistance protein-mediated doxorubicin resistance by binding the multidrug resistance protein.
Prediction of efficacy in individual patients
Autophagy dependency and metabolic stress levels of tumour cells vary widely depending on the tumour type and progression stage. Therefore, reliable measurements to predict tumour sensitivity to autophagy inhibition would be extremely useful for patient selection in clinical practice . As mentioned earlier, the status of tumour suppressor p53 can affect CQ efficacy, but other CQ sensitivity indicators have been identified as well.
First, EGFR overexpressing tumour cells, high levels of STAT3 activity, loss of caveolin-1, Akt- and Myc- driven tumour cells, and argininosuccinate synthetase enzyme deficiency are all associated with a high autophagy dependency and are therefore more sensitive to CQ administration [16, 28, 119, 127–129]. Next, there is still discussion about the effect of the oncogenic BRAF (V600E) mutation on autophagy dependency of tumour cells [47, 130, 131]. In addition, evidence has shown that autophagy is induced by the tumour suppressor alternative reading frame, but it should still be clarified whether this is cytotoxic or protective autophagy before we can determine whether CQ administration would exert beneficial effects . Moreover, oncogenic Ras, and especially Kras, mutation has also been suggested as an indicator of autophagy dependency and susceptibility to CQ [27, 133], but two other studies have reported that this mutation is not a reliable indicator [134, 135]. As mentioned earlier, however, HCQ has been shown to promote tumour growth in Ras-driven pancreatic tumours developing without p53 (KrasG12D/+ p53–/–) [35, 36]. Cells with the IDH1/2 mutations are metabolically vulnerable to CQ treatment, because they depend on glutaminolysis and autophagy, which is inhibited by CQ .
Autophagy dependency is higher in case of nutritional stress, as shown in mesothelioma cells , and neuroendocrine lung tumour cells are more sensitive to autophagy inhibition than non-neuroendocrine lung tumour cells .
Finally, an in vitro study in four human glioma cell lines observed that higher steady-state mitochondrial membrane potential values, representing mitochondrial stability, can predict cancer cell resistance to CQ treatment .Go to:
The final goal of this literature review was to inform further research and trials on repurposing CQ and HCQ as anti-cancer agents, as done previously for other agents . In addition, the ideal dose, route of administration, and therapeutic schedule that should be applied in anti-cancer therapy was explored. Finally, the potential difference in efficacy and toxicity between CQ and HCQ has been investigated.
Efficacy of CQ and HCQ in anti-cancer therapy
The vast majority of preclinical studies on the effect of CQ monotherapy in cancer have reported a positive therapeutic effect, but the study parameters, doses, animal models and tumour types differ strongly between studies, complicating the interpretation of the results. Preclinical studies investigating the effect of HCQ in cancer are limited. Therefore, follow-up in vivo studies are warranted. A risk of publication bias exists so we cannot guarantee that all negative results have been reported.
Combination therapy with CQ or HCQ and existing anti-cancer therapies has been extensively studied in preclinical research, both in vitro and in vivo. The majority of these studies have reported an improved therapeutic efficacy as compared with monotherapy with existing anti-cancer drugs. Most studies hypothesise that CQ and HCQ could increase the efficacy of other anti-cancer drugs by blocking pro-survival autophagy. Because not all studies measured autophagy levels in vivo, it is difficult to determine to what extent the other proposed mechanisms play a role. Table 2 is limited to studies that tested CQ or HCQ in combination with conventional anti-cancer agents in vivo, but there are many other combinations that have only been tested in vitro.
Finally, multiple clinical trials have investigated, or are going to investigate, the use of CQ and HCQ in different cancer types, always in combination with other anti-cancer drugs. The availability of clinical results is limited now, as most trials are still recruiting or ongoing, and those that have been completed focused primarily on safety and tolerability of CQ and HCQ in cancer. In short, these drugs have been found safe and tolerable in all completed studies and the anti-cancer effect of both compounds is promising. However, as many clinical trials are still ongoing, a definite conclusion on the repurposing intent of CQ and HCQ in anti-cancer therapy is pending. Still, data from first clinical trials and additional preclinical data point to a potential positive implementation of these drugs in anti-cancer treatment.
Doses, route of administration and therapeutic schedule
In preclinical experiments, varying CQ and HCQ doses have been used, but most of the applied doses can be extrapolated to human doses. However, whether the dose to achieve autophagy inhibition, induction of apoptosis and tumour normalisation is achievable in humans remains an open question that would require collecting additional data in humans . Clinical trials have shown that daily doses between 150 and 500 mg for CQ and daily doses between 400 and 1200 mg for HCQ are safe and well tolerated, but two studies identified 600-mg HCQ daily as the MTD. HCQ is often administered twice daily to limit plasma fluctuations and toxicity. Of note, Pascolo recommended 10 mg/kg as the maximum realistic clinical dosage of CQ, but the recommended dose and MTD of CQ and HCQ might vary dependent on the tumour type and the concomitantly administered anti-cancer treatments.
Pascolo also suggests that timing of administration is of great importance. CQ must be administered after chemotherapy and not before, which is supported by data in a mouse model of colorectal cancer treated with gemcitabine .
CQ or HCQ?
HCQ has been reported to have less side effects than CQ (e.g. less risk of retinal toxicity) [9, 140, 141], so it can be administered in higher doses for human use. Currently it is not clear yet whether there are differences in anti-cancer treatment efficacy between CQ and HCQ. The clinical trials that have already been completed suggest that CQ might be more efficacious than HCQ. However, no comparative clinical trial has been set up to confirm this hypothesis.
Yet, based on chemical structure, the altered safety and efficacy can be ascribed to the additional hydroxyl group in HCQ, causing pharmacokinetic differences that are essential for the working mechanism of the drugs (e.g. pKa alteration leading to differences in biprotonation and distribution) [14, 140].
More than 30 clinical trials are currently ongoing (Feb 2017). The results of these trials may indicate which tumour types are most sensitive to CQ and HCQ treatment, and which combination therapies can be beneficial. Additional preclinical studies could further characterise the most relevant mechanisms of action and their individual importance in anti-cancer therapy. Finally, CQ analogues and other more specific autophagy inhibitory agents are also under investigation for the treatment of cancer patients (e.g. Lys05) [142–146].Go to:
CQ and HCQ have been studied in multiple preclinical cancer models and have demonstrated activity on several cancer-supporting pathways and in combination with a broad range of other therapies. Our review has highlighted the interesting multi-faceted actions of CQ and HCQ against cancer, making these drugs attractive for this complex disease [147, 148].
Even though it is too soon to make definite conclusions about the overall effect of CQ and HCQ in anti-cancer treatments, the clinical data already available are encouraging to further explore their potential as anti-cancer agents, with a preference for CQ. Until now, most clinical evidence was found in patients with glioblastoma and brain metastases and in patients with BRAF mutations, but some promising effects have been reported in patients with lung cancer, multiple myeloma and sarcoma as well. Although the side effects of CQ and HCQ are minor in comparison with conventional anti-cancer therapy, the possibility of retinal toxicity in trials planning long-term CQ and HCQ exposure requires the implementation of ophthalmologic monitoring. More than 30 clinical studies are currently evaluating HCQ and CQ in different cancers, most of them with the rationale to increase the efficacy of other anti-cancer therapies through inhibition of treatment-induced autophagy. The first clinical trials with CQ and HCQ have focused on the toxicity of different CQ doses in multiple populations and new trials should now focus on rigorous evaluation of efficacy.Go to:
Conflicts of interest
The authors declare that they have no conflicts of interest.Go to:
Primary authors: Ciska Verbaanderd and Gauthier Bouche. Contributing authors: Hannelore Maes, Marco Schaaf, Vikas P Sukhatme, Pan Pantziarka, Vidula Sukhatme and Patrizia Agostinis. All authors read and approved the final manuscript.Go to:
1. Ben-Zvi I, et al. Hydroxychloroquine: from malaria to autoimmunity. Clinical Reviews in Allergy and Immunology. 2012;42:145–153. doi: 10.1007/s12016-010-8243-x. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
3. Anon (n.d.) Avloclor tablets – summary of product characteristics (SPC) – (eMC) [15 January 2016]. [online] Available from: https://www.medicines.org.uk/emc/medicine/2272.4. Anon (n.d.) Plaquenil 200mg film-coated tablets – summary of product characteristics (SPC) – (eMC) [15 January 2016]. [online] Available from: https://www.medicines.org.uk/emc/medicine/6977.
5. Lee S-J, et al. The role of antimalarial agents in the treatment of SLE and lupus nephritis. Nature Reviews Nephrology. 2011;7(12):718–729. doi: 10.1038/nrneph.2011.150. [PubMed] [CrossRef] [Google Scholar]
6. Dubois EL. Antimalarials in the management of discoid and systemic lupus erythematosus. Seminars in Arthritis and Rheumatism. 1978;8(1):33–51. doi: 10.1016/0049-0172(78)90033-1. [PubMed] [CrossRef] [Google Scholar]
8. Costedoat-Chalumeau N, et al. Cardiomyopathy related to antimalarial therapy with illustrative case report. Cardiology. 2007;107(2):73–80. doi: 10.1159/000094079. [PubMed] [CrossRef] [Google Scholar]
9. Browning DJ. Pharmacology of chloroquine and hydroxychloroquine. Hydroxychloroquine and Chloroquine Retinopathy. 2014. pp. 35–63. [CrossRef]
10. Costedoat-Chalumeau N, et al. A critical review of the effects of hydroxychloroquine and chloroquine on the eye. Clinical Reviews in Allergy & Immunology. 2015;49(3):317–326. doi: 10.1007/s12016-015-8469-8. [PubMed] [CrossRef] [Google Scholar]
11. Nagaratnam N, et al. Aplasia and leukaemia following chloroquine therapy. Postgraduate Medical Journal. 1978;54(628):108–112. doi: 10.1136/pgmj.54.628.108. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
13. Marmor MF, et al. Recommendations on screening for chloroquine and hydroxychloroquine retinopathy (2016 revision) Ophthalmology. 2016;123(6):1386–1394. doi: 10.1016/j.ophtha.2016.01.058. [PubMed] [CrossRef] [Google Scholar]
14. Warhurst DC, et al. Hydroxychloroquine is much less active than chloroquine against chloroquine-resistant plasmodium falciparum, in agreement with its physicochemical properties. The Journal of Antimicrobial Chemotherapy. 2003;52(2):188–193. doi: 10.1093/jac/dkg319. [PubMed] [CrossRef] [Google Scholar]
15. Day RO, et al., editors. Birkhäuser: Basel; 2005. Antirheumatic Therapy: Actions and Outcomes. [Google Scholar]16. Jutten B, et al. EGFR overexpressing cells and tumors are dependent on autophagy for growth and survival. Radiotherapy and Oncology. 2013;108(3):479–483. doi: 10.1016/j.radonc.2013.06.033. [PubMed] [CrossRef] [Google Scholar]
17. Kim EL, et al. Chloroquine activates the p53 pathway and induces apoptosis in human glioma cells. Neuro-Oncology. 2010;12(4):389–400. doi: 10.1093/neuonc/nop046. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
18. Song YJ, et al. Autophagy contributes to the survival of CD133+ liver cancer stem cells in the hypoxic and nutrient-deprived tumor microenvironment. Cancer Letters. 2013;339(1):70–81. doi: 10.1016/j.canlet.2013.07.021. [PubMed] [CrossRef] [Google Scholar]
19. Hu T, et al. Chloroquine inhibits hepatocellular carcinoma cell growth in vitro and in vivo. Oncology Reports. 2016;35(1):43–49. doi: 10.3892/or.2015.4380. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
20. Lakhter AJ, et al. Chloroquine promotes apoptosis in melanoma cells by inhibiting BH3 domain-mediated PUMA degradation. The Journal of Investigative Dermatology. 2013;133(9):2247–2254. doi: 10.1038/jid.2013.56. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
21. Zheng Y, et al. Chloroquine inhibits colon cancer cell growth in vitro and tumor growth in vivo via induction of apoptosis. Cancer Investigation. 2009;27(3):286–292. doi: 10.1080/07357900802427927. [PubMed] [CrossRef] [Google Scholar]
22. Jiang PD, et al. Antitumor and antimetastatic activities of chloroquine diphosphate in a murine model of breast cancer. Biomedicine and Pharmacotherapy. 2010;64(9):609–614. doi: 10.1016/j.biopha.2010.06.004. [PubMed] [CrossRef] [Google Scholar]
23. Loehberg CR, et al. Ataxia telangiectasia-mutated and p53 are potential mediators of chloroquine-induced resistance to mammary carcinogenesis. Cancer Research. 2007;67(24):12026–12033. doi: 10.1158/0008-5472.CAN-07-3058. [PubMed] [CrossRef] [Google Scholar]
24. Maclean KH, et al. Targeting lysosomal degradation induces p53-dependent cell death and prevents cancer in mouse models of lymphomagenesis. The Journal of Clinical Investigation. 2008;118(1):79–88. doi: 10.1172/JCI33700. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
25. Sun K, et al. Paradoxical role of autophagy in the dysplastic and tumor-forming stages of hepatocarcinoma development in rats. Cell Death & Disease. 2013;4:e501. doi: 10.1038/cddis.2013.35. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
28. Maycotte P, et al. STAT3-mediated autophagy dependence identifies subtypes of breast cancer where autophagy inhibition can be efficacious. Cancer Research. 2015;74(9):2579–2590. doi: 10.1158/0008-5472.CAN-13-3470. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
29. Hiraki K, Kimura I. Studies on the treatment of malignant tumors with fibroblast-inhibiting agent. II. Effects of chloroquine on animal tumors. Acta Medicinae Okayama. 1963;17:239–252. [PubMed] [Google Scholar]
30. Pellegrini P, et al. Acidic extracellular pH neutralizes the autophagy-inhibiting activity of chloroquine: implications for cancer therapies. Autophagy. 2014;10(4):562–571. doi: 10.4161/auto.27901. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
31. Rouschop KMA, et al. The unfolded protein response protects human tumor cells during hypoxia through regulation of the autophagy genes MAP1LC3B and ATG5. The Journal of Clinical Investigation. 2010;120(1):127–141. doi: 10.1172/JCI40027. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
32. Dutta P, et al. Enhanced growth of mammary adenocarcinoma in rats by chloroquine and quinacrine. Cancer Letters. 1994;76:113–119. doi: 10.1016/0304-3835(94)90386-7. [PubMed] [CrossRef] [Google Scholar]
33. Yamaguchi I, et al. Influence of host conditions upon the growth pattern of transplanted tumors. Tohoku Journal of Experimental Medicine. 1966;90:291–301. doi: 10.1620/tjem.90.291. [PubMed] [CrossRef] [Google Scholar]
34. Chi C, et al. Disruption of lysosome function promotes tumor growth and metastasis in drosophila. The Journal of Biological Chemistry. 2010;285(28):21817–21823. doi: 10.1074/jbc.M110.131714. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
36. Jonckheere N, et al. Of autophagy and in vivo pancreatic carcinogenesis: the p53 status matters! Clinics and Research in Hepatology and Gastroenterology. 2014;38(4):423–425. doi: 10.1016/j.clinre.2014.04.009. [PubMed] [CrossRef] [Google Scholar]
38. Briceño E, et al. Therapy of glioblastoma multiforme improved by the antimutagenic chloroquine. Neurosurgical Focus. 2003;14(2):e3. doi: 10.3171/foc.2003.14.2.4. [PubMed] [CrossRef] [Google Scholar]
39. Sotelo J, et al. Adding chloroquine to conventional treatment for glioblastoma multiforme: a randomized, double-blind, placebo-controlled trial. Annals of Internal Medicine. 2006;144:337–343. doi: 10.7326/0003-4819-144-5-200603070-00008. [PubMed] [CrossRef] [Google Scholar]
40. Gilbert MR. New treatments for malignant gliomas: careful evaluation and cautious optimism required. Annals of Iinternal Medicine. 2006;144(5):371–373. doi: 10.7326/0003-4819-144-5-200603070-00015. [PubMed] [CrossRef] [Google Scholar]
41. Briceño E, et al. Institutional experience with chloroquine as an adjuvant to the therapy for glioblastoma multiforme. Surgical Neurology. 2007;67(4):388–391. doi: 10.1016/j.surneu.2006.08.080. [PubMed] [CrossRef] [Google Scholar]
42. Bilger A, et al. FET-PET-based reirradiation and chloroquine in patients with recurrent glioblastoma: first tolerability and feasibility results. Strahlentherapie und Onkologie. 2014;190(10):957–961. doi: 10.1007/s00066-014-0693-2. [PubMed] [CrossRef] [Google Scholar]
43. Rojas-Puentes LL, et al. Phase II randomized, double-blind, placebo-controlled study of whole-brain irradiation with concomitant chloroquine for brain metastases. Radiation Oncology (London, England) 2013;8:209. doi: 10.1186/1748-717X-8-209. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
44. Eldredge HB, et al. Concurrent whole brain radiotherapy and short-course chloroquine in patients with brain metastases: a pilot trial. Journal of Radiation Oncology. 2013;2(3):315–321. doi: 10.1007/s13566-013-0111-x. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
45. Munshi A, et al. Unusual intensification of skin reactions by chloroquine use during breast radiotherapy. Acta Oncologica (Stockholm, Sweden) 2008;47(2):318–319. doi: 10.1080/02841860701491058. [PubMed] [CrossRef] [Google Scholar]
46. Rustogi A, et al. Unexpected skin reaction induced by radiotherapy after chloroquine use. The Lancet. Oncology. 2006;7(7):608–609. doi: 10.1016/S1470-2045(06)70763-X. [PubMed] [CrossRef] [Google Scholar]
47. Levy JMM, et al. Autophagy inhibition improves chemosensitivity in BRAFV600E brain tumors. Cancer Discovery. 2014;4(7):773–780. doi: 10.1158/2159-8290.CD-14-0049. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
48. Mulcahy Levy JM, et al. Autophagy inhibition overcomes multiple mechanisms of resistance to BRAF inhibition in brain tumors. eLife. 2017;6:358–367. doi: 10.7554/eLife.19671. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
49. Montanari F, et al. A phase II trial of chloroquine in combination with bortezomib and cyclophosphamide in patients with relapsed and refractory multiple myeloma. Blood. 2014;124(21):5775. [Google Scholar]
50. Kyle RA, et al. Multiple myeloma resistant to melphalan (NSC-8806) treated with cyclophosphamide (NSC-26271), prednisone (NSC-10023), and chloroquine (NSC-187208) Cancer Chemotherapy Reports. Part 1. 1975;59(3):557–562. [PubMed] [Google Scholar]
51. Rangwala R, et al. Combined MTOR and autophagy inhibition: phase I trial of hydroxychloroquine and temsirolimus in patients with advanced solid tumors and melanoma. Autophagy. 2014;10(8):1391–1402. doi: 10.4161/auto.29119. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
52. Rangwala R, et al. Phase I trial of hydroxychloroquine with dose-intense temozolomide in patients with advanced solid tumors and melanoma. Autophagy. 2014;10(8):1369–1379. doi: 10.4161/auto.29118. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
53. Mahalingam D, et al. Combined autophagy and HDAC inhibition: a phase I safety, tolerability, pharmacokinetic, and pharmacodynamic analysis of hydroxychloroquine in combination with the HDAC inhibitor vorinostat in patients with advanced solid tumors. Autophagy. 2014;10(8):1403–1414. doi: 10.4161/auto.29231. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
54. Chi K-H, et al. Addition of rapamycin and hydroxychloroquine to metronomic chemotherapy as a second line treatment results in high salvage rates for refractory metastatic solid tumors: a pilot safety and effectiveness analysis in a small patient cohort. Oncotarget. 2015;6(18):16735–16745. doi: 10.18632/oncotarget.3793. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
55. Rosenfeld MR, et al. A phase I/II trial of hydroxychloroquine in conjunction with radiation therapy and concurrent and adjuvant temozolomide in patients with newly diagnosed glioblastoma multiforme. Autophagy. 2014;10(8):1359–1368. doi: 10.4161/auto.28984. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
56. Stupp R, et al. Radiotherapy plus concomitant and adjuvant temozolomide for glioblastoma. The New England Journal of Medicine. 2005;352(10):987–996. doi: 10.1056/NEJMoa043330. [PubMed] [CrossRef] [Google Scholar]
57. Goldberg SB, et al. A phase I study of erlotinib and hydroxychloroquine in advanced non-small-cell lung cancer. Journal of Thoracic Oncology. 2012;7(10):1602–1608. doi: 10.1097/JTO.0b013e318262de4a. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
58. Leung L-SB, et al. Rapid onset of retinal toxicity from high-dose hydroxychloroquine given for cancer therapy. American Journal of Ophthalmology. 2015;160(4):799.e1–805.e1. doi: 10.1016/j.ajo.2015.07.012. [PubMed] [CrossRef] [Google Scholar]
59. Vogl DT, et al. Combined autophagy and proteasome inhibition: a phase 1 trial of hydroxychloroquine and bortezomib in patients with relapsed/refractory myeloma. Autophagy. 2014;10(8):1380–1390. doi: 10.4161/auto.29264. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
60. Boone BA, et al. Safety and biologic response of pre-operative autophagy inhibition in combination with gemcitabine in patients with pancreatic adenocarcinoma. Annals of Surgical Oncology. 2015;22(13):4402–4410. doi: 10.1245/s10434-015-4566-4. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
61. Wolpin BM, et al. Phase II and pharmacodynamic study of autophagy inhibition using hydroxychloroquine in patients with metastatic pancreatic adenocarcinoma. The Oncologist. 2014;19(6):637–638. doi: 10.1634/theoncologist.2014-0086. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
62. Chi M-S, et al. Double autophagy modulators reduce 2-deoxyglucose uptake in sarcoma patients. Oncotarget. 2015;6(30):29808–29817. doi: 10.18632/oncotarget.5060. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
64. Sehgal A, et al. You eat what you are: autophagy inhibition as a therapeutic strategy in leukemia. Leukemia. 2014;29(3):517–525. doi: 10.1038/leu.2014.349. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
65. Parzych KR, Klionsky DJ. An overview of autophagy: morphology, mechanism, and regulation. Antioxidants & Redox Signaling. 2014;20(3):460–473. doi: 10.1089/ars.2013.5371. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
66. Viry E, et al. Autophagy: an adaptive metabolic response to stress shaping the antitumor immunity. Biochemical Pharmacology. 2014;92(1):1–12. doi: 10.1016/j.bcp.2014.07.006. [PubMed] [CrossRef] [Google Scholar]
67. Cicchini M, et al. Molecular pathways: autophagy in cancer–a matter of timing and context. Clinical Cancer Research. 2015;21(3):498–504. doi: 10.1158/1078-0432.CCR-13-2438. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
70. Rebecca VW, Amaravadi RK. Emerging strategies to effectively target autophagy in cancer. Oncogene. 2016;35(1):1–11. doi: 10.1038/onc.2015.99. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
71. Townsend KN, et al. Autophagy inhibition in cancer therapy: metabolic considerations for antitumor immunity. Immunological Reviews. 2012;249(1):176–194. doi: 10.1111/j.1600-065X.2012.01141.x. [PubMed] [CrossRef] [Google Scholar]
72. Loehberg CR, et al. Akt and p53 are potential mediators of reduced mammary tumor growth by cloroquine and the mTOR inhibitor RAD001. Biochemical Pharmacology. 2012;83(4):480–488. doi: 10.1016/j.bcp.2011.11.022. [PubMed] [CrossRef] [Google Scholar]
74. Zhang Y, et al. Chloroquine inhibits MGC803 gastric cancer cell migration via the Toll-like receptor 9/nuclear factor kappa B signaling pathway. Molecular Medicine Reports. 2015;11(2):1366–1371. doi: 10.3892/mmr.2014.2839. [PubMed] [CrossRef] [Google Scholar]
75. Väisänen MR, et al. Expression of toll-like receptor-9 is associated with poor progression-free survival in prostate cancer. Oncology Letters. 2013;5(12):1659–1663. [PMC free article] [PubMed] [Google Scholar]
76. Mohamed FE, et al. Effect of toll-like receptor 7 and 9 targeted therapy to prevent the development of hepatocellular carcinoma. Liver International. 2015;35(3):1063–1076. doi: 10.1111/liv.12626. [PubMed] [CrossRef] [Google Scholar]
77. Kuznik A, et al. Mechanism of endosomal TLR inhibition by antimalarial drugs and imidazoquinolines. The Journal of Immunology. 2011;186(8):4794–4804. doi: 10.4049/jimmunol.1000702. [PubMed] [CrossRef] [Google Scholar]
78. Sandholm J, et al. Hypoxia regulates toll-like receptor-9 expression and invasive function in human brain cancer cells in vitro. Oncology Letters. 2014;8:266–274. [PMC free article] [PubMed] [Google Scholar]
79. Tuomela J, et al. Low TLR9 expression defines an aggressive subtype of triple-negative breast cancer. Breast Cancer Research and Treatment. 2012;135:481–493. doi: 10.1007/s10549-012-2181-7. [PubMed] [CrossRef] [Google Scholar]
81. Sun X, et al. CXCL12 / CXCR4 / CXCR7 chemokine axis and cancer progression. Cancer Metastasis Reviews. 2010;29(4):709–722. doi: 10.1007/s10555-010-9256-x. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
82. Kim J, et al. Identification of anti-malarial compounds as novel antagonists to chemokine receptor CXCR4 in pancreatic cancer cells. PloS One. 2012;7(2):e31004. doi: 10.1371/journal.pone.0031004. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
83. Balic A, et al. Chloroquine targets pancreatic cancer stem cells via inhibition of CXCR4 and hedgehog signaling. Molecular Cancer Therapeutics. 2014;13(7):1758–1771. doi: 10.1158/1535-7163.MCT-13-0948. [PubMed] [CrossRef] [Google Scholar]
84. Bieging KT, et al. Unravelling mechanisms of p53-mediated tumour suppression. Nature Reviews Cancer. 2014;14(5):359–370. doi: 10.1038/nrc3711. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
85. Zhou Q, et al. Control of mammary tumor cell growth in vitro by novel cell differentiation and apoptosis agents. Breast Cancer Research and Treatment. 2002;75(2):107–117. doi: 10.1023/A:1019698807564. [PubMed] [CrossRef] [Google Scholar]
86. Lee SW, et al. The synergistic effect of combination temozolomide and chloroquine treatment is dependent on autophagy formation and p53 status in glioma cells. Cancer Letters. 2015;360(2):195–204. doi: 10.1016/j.canlet.2015.02.012. [PubMed] [CrossRef] [Google Scholar]
87. Amaravadi R, Debnath J. Mouse models address key concerns regarding autophagy inhibition in cancer therapy. Cancer Discovery. 2014;4(8):873–875. doi: 10.1158/2159-8290.CD-14-0618. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
88. Yang A, Kimmelman AC. Inhibition of autophagy attenuates pancreatic cancer growth independent of TP53/TRP53 status. Autophagy. 2014;10(9):1683–1684. doi: 10.4161/auto.29961. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
89. Liu F, et al. Chloroquine potentiates the anti-cancer effect of lidamycin on non-small cell lung cancer cells in vitro. Acta Pharmacologica Sinica. 2014;35(5):645–652. doi: 10.1038/aps.2014.3. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
90. Geng Y, et al. Chloroquine-induced autophagic vacuole accumulation and cell death in glioma cells is p53 independent. Neuro-Oncology. 2010;12(5):473–481. [PMC free article] [PubMed] [Google Scholar]
91. Burikhanov R, et al. Chloroquine-inducible par-4 secretion is essential for tumor cell apoptosis and inhibition of metastasis. Cell Reports. 2017;18(2):508–519. doi: 10.1016/j.celrep.2016.12.051. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
92. Amaravadi RK. PUMA: a puzzle piece in chloroquine’s antimelanoma activity. The Journal of Investigative Dermatology. 2013;133(9):2133–2135. doi: 10.1038/jid.2013.135. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
94. Choi M-M, et al. Inhibitory properties of nerve-specific human glutamate dehydrogenase isozyme by chloroquine. Journal of Biochemistry and Molecular Biology. 2007;40(6):1077–1082. [PubMed] [Google Scholar]
95. Jarzyna R, et al. Chloroquine is a potent inhibitor of glutamate dehydrogenase in liver and kidney-cortex of rabbit. Pharmacological Research : The Official Journal of the Italian Pharmacological Society. 1997;35(1):79–84. doi: 10.1006/phrs.1996.0108. [PubMed] [CrossRef] [Google Scholar]
96. Jarzyna R, et al. The inhibition of gluconeogenesis by chloroquine contributes to its hypoglycaemic action. European Journal of Pharmacology. 2001;428(3):381–388. doi: 10.1016/S0014-2999(01)01221-3. [PubMed] [CrossRef] [Google Scholar]
97. Molenaar RJ, et al. Study protocol of a phase IB/II clinical trial of metformin and chloroquine in patients with IDH1-mutated or IDH2-mutated solid tumours. BMJ Open. 2017;7(6):e014961. doi: 10.1136/bmjopen-2016-014961. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
98. Lagneaux L, et al. Early induction of apoptosis in B-chronic lymphocytic leukaemia cells by hydroxychloroquine: activation of caspase-3 and no protection by survival factors. British Journal of Haematology. 2001;112(2):344–352. doi: 10.1046/j.1365-2141.2001.02553.x. [PubMed] [CrossRef] [Google Scholar]
99. Lagneaux L, et al. Hydroxychloroquine-induced apoptosis of chronic lymphocytic leukemia involves activation of caspase-3 and modulation of Bcl-2/bax/ratio. Leukemia & Lymphoma. 2002;43(5):1087–1095. doi: 10.1080/10428190290021506. [PubMed] [CrossRef] [Google Scholar]
100. Park BC, et al. Chloroquine-induced nitric oxide increase and cell death is dependent on cellular GSH depletion in A172 human glioblastoma cells. Toxicology Letters. 2008;178(1):52–60. doi: 10.1016/j.toxlet.2008.02.003. [PubMed] [CrossRef] [Google Scholar]
101. Jiang P, et al. Cell growth inhibition, G2/M cell cycle arrest, and apoptosis induced by chloroquine in human breast cancer cell line Bcap-37. Cellular physiology and biochemistry : international journal of experimental cellular physiology, biochemistry, and pharmacology. 2008;22(5–6):431–440. doi: 10.1159/000185488. [PubMed] [CrossRef] [Google Scholar]
102. Fan C, et al. Chloroquine inhibits cell growth and induces cell death in A549 lung cancer cells. Bioorganic & Medicinal Chemistry. 2006;14(9):3218–3222. doi: 10.1016/j.bmc.2005.12.035. [PubMed] [CrossRef] [Google Scholar]
103. Rahim R, Strobl JS. Hydroxychloroquine, chloroquine, and all-trans retinoic acid regulate growth, survival, and histone acetylation in breast cancer cells. Anti-Cancer Drugs. 2009;20(8):736–745. doi: 10.1097/CAD.0b013e32832f4e50. [PubMed] [CrossRef] [Google Scholar]
104. Justilien V, Fields AP. Molecular pathways: novel approaches for improved therapeutic targeting of hedgehog signaling in cancer stem cells. Clinical Cancer Research. 2015;21:505–513. doi: 10.1158/1078-0432.CCR-14-0507. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
105. Thongchot S, et al. Chloroquine exerts anti-metastatic activities under hypoxic conditions in cholangiocarcinoma cells. Asian Pacific Journal of Cancer Prevention : APJCP. 2015;16(5):2031–2035. doi: 10.7314/APJCP.2015.16.5.2031. [PubMed] [CrossRef] [Google Scholar]
106. Choi DS, et al. Chloroquine eliminates cancer stem cells through deregulation of Jak2 and DNMT1. Stem Cells (Dayton, Ohio) 2014;32(9):2309–2323. doi: 10.1002/stem.1746. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
107. Liang DH, et al. The autophagy inhibitor chloroquine targets cancer stem cells in triple negative breast cancer by inducing mitochondrial damage and impairing DNA break repair. Cancer Letters. 2016;376(2):249–258. doi: 10.1016/j.canlet.2016.04.002. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
108. Inoue S, et al. Antimelanoma activity of chloroquine, an antimalarial agent with high affinity for melanin. Pigment Cell Research / Sponsored by the European Society for Pigment Cell Research and the International Pigment Cell Society. 1993;6(5):354–8. doi: 10.1111/j.1600-0749.1993.tb00613.x. [PubMed] [CrossRef] [Google Scholar]
112. Pascolo S. Time to use a dose of chloroquine as an adjuvant to anti-cancer chemotherapies. European Journal of Pharmacology. 2016;771:139–144. doi: 10.1016/j.ejphar.2015.12.017. [PubMed] [CrossRef] [Google Scholar]
114. Jain RK. Normalization of tumor vasculature: an emerging concept in antiangiogenic therapy. Science (New York, NY) 2005;307(5706):58–62. doi: 10.1126/science.1104819. [PubMed] [CrossRef] [Google Scholar]
115. Carmeliet P, Jain RK. Principles and mechanisms of vessel normalization for cancer and other angiogenic diseases. Nature Reviews Drug Discovery. 2011;10(6):417–427. doi: 10.1038/nrd3455. [PubMed] [CrossRef] [Google Scholar]
116. Maes H, et al. How to teach an old dog new tricks: autophagy-independent action of chloroquine on the tumor vasculature. Autophagy. 2014;10(11):2082–2084. doi: 10.4161/auto.36259. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
117. Hagihara N, et al. Vascular protection by chloroquine during brain tumor therapy with Tf-CRM107 advances in brief vascular protection by chloroquine during brain tumor therapy with Tf-CRM107. Cancer Research. 2000;60(2):230–234. [PubMed] [Google Scholar]
118. McAllister SS, Weinberg RA. The tumour-induced systemic environment as a critical regulator of cancer progression and metastasis. Nature Cell Biology. 2014;16(8):717–727. doi: 10.1038/ncb3015. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
119. Ko Y-H, et al. Glutamine fuels a vicious cycle of autophagy in the tumor stroma and oxidative mitochondrial metabolism in epithelial cancer cells: implications for preventing chemotherapy resistance. Cancer Biology & Therapy. 2011;12(12):1085–1097. doi: 10.4161/cbt.12.12.18671. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
120. Martinez-Outschoorn UE, et al. Tumor cells induce the cancer associated fibroblast phenotype via caveolin-1 degradation: implications for breast cancer and DCIS therapy with autophagy inhibitors. Cell Cycle (Georgetown, TX) 2010;9(12):2423–2433. doi: 10.4161/cc.9.12.12048. [PubMed] [CrossRef] [Google Scholar]
122. Lee CM, Tannock IF. Inhibition of endosomal sequestration of basic anticancer drugs: influence on cytotoxicity and tissue penetration. British Journal of Cancer. 2006;94(6):863–869. doi: 10.1038/sj.bjc.6603010. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
124. Maycotte P, et al. Chloroquine sensitizes breast cancer cells to chemotherapy independent of autophagy. Autophagy. 2012;8(2):200–212. doi: 10.4161/auto.8.2.18554. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
125. Vezmar M, Georges E. Direct binding of chloroquine to the multidrug resistance protein (MRP): possible role for MRP in chloroquine drug transport and resistance in tumor cells. Biochemical Pharmacology. 1998;56(6):733–742. doi: 10.1016/S0006-2952(98)00217-2. [PubMed] [CrossRef] [Google Scholar]
126. Vezmar M, Georges E. Reversal of MRP-mediated doxorubicin resistance with quinoline-based drugs. Biochemical Pharmacology. 2000;59(10):1245–1252. doi: 10.1016/S0006-2952(00)00270-7. [PubMed] [CrossRef] [Google Scholar]
127. Maes H, et al. Dynamic interplay between autophagic flux and Akt during melanoma progression in vitro. Experimental Dermatology. 2014;23(2):101–106. doi: 10.1111/exd.12298. [PubMed] [CrossRef] [Google Scholar]
128. Battisti S, et al. Nutritional stress and arginine auxotrophy confer high sensitivity to chloroquine toxicity in mesothelioma cells. American Journal of Respiratory Cell and Molecular Biology. 2012;46(4):498–506. doi: 10.1165/rcmb.2011-0195OC. [PubMed] [CrossRef] [Google Scholar]
129. Amaravadi RK, et al. Autophagy inhibition enhances therapy-induced apoptosis in a Myc-induced model of lymphoma. The Journal of Clinical Investigation. 2007;117(2):326–336. doi: 10.1172/JCI28833. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
130. Levy JM, et al. Using BRAF(V600E) as a marker of autophagy dependence in pediatric brain tumors. Autophagy. 2014;10(11):2077–2078. doi: 10.4161/auto.36138. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
131. Egger ME, et al. Inhibition of autophagy with chloroquine is effective in melanoma. The Journal of Surgical Research. 2013;184(1):274–281. doi: 10.1016/j.jss.2013.04.055. [PubMed] [CrossRef] [Google Scholar]
134. Morgan MJ, et al. Regulation of autophagy and chloroquine sensitivity by oncogenic RAS in vitro is context-dependent. Autophagy. 2014;10(10):1814–1826. doi: 10.4161/auto.32135. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
135. Eng CH, et al. Macroautophagy is dispensable for growth of KRAS mutant tumors and chloroquine efficacy. Proceedings of the National Academy of Sciences of the United States of America. 2016;113(1):182–187. doi: 10.1073/pnas.1515617113. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
136. Hong S-K, et al. Autophagy sensitivity of neuroendocrine lung tumor cells. International Journal of Oncology. 2013;43(6):2031–2038. doi: 10.3892/ijo.2013.2136. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
137. Vessoni AT, et al. Chloroquine-induced glioma cells death is associated with mitochondrial membrane potential loss, but not oxidative stress. Free Radical Biology and Medicine. 2016;90:91–100. doi: 10.1016/j.freeradbiomed.2015.11.008. [PubMed] [CrossRef] [Google Scholar]
139. Buch I, et al. Schedule-dependent synergy of chloroquine with chemotherapy for anti-cancer treatment. Cancer Research and Oncology: Open Access. 2016;2(2) [Google Scholar]
140. Schroeder RL, Gerber JP. Chloroquine and hydroxychloroquine binding to melanin: some possible consequences for pathologies. Toxicology Reports. 2014;1:963–968. doi: 10.1016/j.toxrep.2014.10.019. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
141. Sundelin SP, Terman A. Different effects of chloroquine and hydroxychloroquine on lysosomal function in cultured retinal pigment epithelial cells. APMIS : acta pathologica, microbiologica, et immunologica Scandinavica. 2002;110(6):481–489. doi: 10.1034/j.1600-0463.2002.100606.x. [PubMed] [CrossRef] [Google Scholar]
142. McAfee Q, et al. Autophagy inhibitor Lys05 has single-agent antitumor activity and reproduces the phenotype of a genetic autophagy deficiency. Proceedings of the National Academy of Sciences of the United States of America. 2012;109(21):8253–8258. doi: 10.1073/pnas.1118193109. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
143. Solomon VR, Lee H. Chloroquine and its analogs: a new promise of an old drug for effective and safe cancer therapies. European Journal of Pharmacology. 2009;625(1–3):220–233. doi: 10.1016/j.ejphar.2009.06.063. [PubMed] [CrossRef] [Google Scholar]
144. Zhang H, et al. Synthesis and in vitro cytotoxicity evaluation of 4-aminoquinoline derivatives. Biomedicine & Pharmacotherapy. 2008;62(2):65–69. doi: 10.1016/j.biopha.2007.04.007. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
145. Goodall ML, et al. Development of potent autophagy inhibitors that sensitize oncogenic BRAF V600E mutant melanoma tumor cells to vemurafenib. Autophagy. 2014;10(6):1120–1136. doi: 10.4161/auto.28594. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
146. Dai J-P, et al. Drug screening for autophagy inhibitors based on the dissociation of Beclin1-Bcl2 complex using BiFC technique and mechanism of eugenol on anti-influenza A virus activity. PloS One. 2013;8(4):e61026. doi: 10.1371/journal.pone.0061026. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
147. Anighoro A, et al. Polypharmacology: challenges and opportunities in drug discovery. Journal of Medicinal Chemistry. 2014;57(19):7874–7887. doi: 10.1021/jm5006463. [PubMed] [CrossRef] [Google Scholar]
149. Reagan-Shaw S, et al. Dose translation from animal to human studies revisited. FASEB Journal : Official Publication of the Federation of American Societies for Experimental Biology. 2008;22(3):659–661. doi: 10.1096/fj.07-9574LSF. [PubMed] [CrossRef] [Google Scholar]
150. Golden EB, et al. Chloroquine enhances temozolomide cytotoxicity in malignant gliomas by blocking autophagy. Neurosurgical Focus. 2014;37(6):E12. doi: 10.3171/2014.9.FOCUS14504. [PubMed] [CrossRef] [Google Scholar]
151. Zanotto-Filho A, et al. Autophagy inhibition improves the efficacy of curcumin/temozolomide combination therapy in glioblastomas. Cancer Letters. 2015;358(2):220–231. doi: 10.1016/j.canlet.2014.12.044. [PubMed] [CrossRef] [Google Scholar]
152. Gaudin D, et al. The effect of DNA repair inhibitors on e response of tumors treated with x-ray and alkylating agents. Proceedings of the Society for Experimental Biology and Medicine (New York, NY) 1971;137(1):202–206. doi: 10.3181/00379727-137-35544. [PubMed] [CrossRef] [Google Scholar]
153. Lefort S, et al. Inhibition of autophagy as a new means of improving chemotherapy efficiency in high-LC3B triple-negative breast cancers. Autophagy. 2014;10(12):2122–2142. doi: 10.4161/15548627.2014.981788. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
154. Yu L, et al. Induction of autophagy counteracts the anticancer effect of cisplatin in human esophageal cancer cells with acquired drug resistance. Cancer Letters. 2014;355:34–45. doi: 10.1016/j.canlet.2014.09.020. [PubMed] [CrossRef] [Google Scholar]
155. Zhang H, et al. Antitumor activity of chloroquine in combination with cisplatin in human gastric cancer xenografts. Asian Pacific Journal of Cancer Prevention. 2015;16:3907–3912. doi: 10.7314/APJCP.2015.16.9.3907. [PubMed] [CrossRef] [Google Scholar]
156. Zhao X, et al. Chloroquine-enhanced efficacy of cisplatin in the treatment of hypopharyngeal carcinoma in xenograft mice. PloS One. 2015;10(4):e01 1–12. [PMC free article] [PubMed] [Google Scholar]
157. Ding Z-B, et al. Autophagy activation in hepatocellular carcinoma contributes to the tolerance of oxaliplatin via reactive oxygen species modulation. Clinical Cancer Research : An Official Journal of the American Association for Cancer Research. 2011;17(19):6229–6238. doi: 10.1158/1078-0432.CCR-11-0816. [PubMed] [CrossRef] [Google Scholar]
158. Selvakumaran M, et al. Autophagy inhibition sensitizes colon cancer cells to antiangiogenic and cytotoxic therapy. Clinical Cancer Research. 2013;19(11):2995–3007. doi: 10.1158/1078-0432.CCR-12-1542. [PubMed] [CrossRef] [Google Scholar]
160. Guo X-L, et al. Targeting autophagy potentiates chemotherapy-induced apoptosis and proliferation inhibition in hepatocarcinoma cells. Cancer Letters. 2012;320(2):171–179. doi: 10.1016/j.canlet.2012.03.002. [PubMed] [CrossRef] [Google Scholar]
161. Sasaki K, et al. Resistance of colon cancer to 5-fluorouracil may be overcome by combination with chloroquine, an in vivo study. Anti-Cancer Drugs. 2012;23(7):675–682. doi: 10.1097/CAD.0b013e328353f8c7. [PubMed] [CrossRef] [Google Scholar]
162. Shoemaker JP, Dagher RK. Remissions of mammary adenocarcinoma in hypothyroid mice given 5-fluorouracil and chloroquine phosphate. Journal of the National Cancer Institute. 1979;62(6):1575–1578. [PubMed] [Google Scholar]
163. Xiong S, et al. Triggering liposomal drug release with a lysosomotropic agent. Journal of Pharmaceutical Sciences. 2010;99(12):5011–5018. doi: 10.1002/jps.22210. [PubMed] [CrossRef] [Google Scholar]
164. Arnold AM, Whitehouse JM. Interaction of VP16-213 with the DNA repair antagonist chloroquine. Cancer Chemotherapy and Pharmacology. 1982;7(2–3):123–126. doi: 10.1007/BF00254533. [PubMed] [CrossRef] [Google Scholar]
165. Cook KL, et al. Hydroxychloroquine inhibits autophagy to potentiate antiestrogen responsiveness in ER+ breast cancer. Clinical Cancer Research : an Official Journal of the American Association for Cancer Research. 2014;20(12):3222–3232. doi: 10.1158/1078-0432.CCR-13-3227. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
166. Seront E, et al. Tumour hypoxia determines the potential of combining mTOR and autophagy inhibitors to treat mammary tumours. British Journal of Cancer. 2013;109(10):2597–2606. doi: 10.1038/bjc.2013.644. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
167. Bray K, et al. Autophagy suppresses RIP kinase-dependent necrosis enabling survival to mTOR inhibition. PloS One. 2012;7(7):e41831. doi: 10.1371/journal.pone.0041831. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
168. Kaneko M, et al. Temsirolimus and chloroquine cooperatively exhibit a potent antitumor effect against colorectal cancer cells. Journal of Cancer Research and Clinical Oncology. 2014;140(5):769–781. doi: 10.1007/s00432-014-1628-0. [PubMed] [CrossRef] [Google Scholar]
169. Xie X, et al. Coordinate autophagy and mTOR pathway inhibition enhances cell death in melanoma. PloS One. 2013;8(1):e55096. doi: 10.1371/journal.pone.0055096. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
170. Rao R, et al. Combination of pan-histone deacetylase inhibitor and autophagy inhibitor exerts superior efficacy against triple-negative human breast cancer cells. Molecular Cancer Therapeutics. 2012;11(4):973–983. doi: 10.1158/1535-7163.MCT-11-0979. [PubMed] [CrossRef] [Google Scholar]
171. Carew JS, et al. Autophagy inhibition enhances vorinostat-induced apoptosis via ubiquitinated protein accumulation. Journal of Cellular and Molecular Medicine. 2010;14(10):2448–2459. doi: 10.1111/j.1582-4934.2009.00832.x. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
172. Ding W-X, et al. Oncogenic transformation confers a selective susceptibility to the combined suppression of the proteasome and autophagy. Molecular Cancer Therapeutics. 2009;8(7):2036–2045. doi: 10.1158/1535-7163.MCT-08-1169. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
173. Hui B, et al. Proteasome inhibitor interacts synergistically with autophagy inhibitor to suppress proliferation and induce apoptosis in hepatocellular carcinoma. Cancer. 2012;118(22):5560–5571. doi: 10.1002/cncr.27586. [PubMed] [CrossRef] [Google Scholar]174. Tang M-C, et al. Chloroquine enhances gefitinib cytotoxicity in gefitinib-resistant nonsmall cell lung cancer cells. PloS One. 2015;10(3):e0119135. doi: 10.1371/journal.pone.0119135. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
175. Dragowska WH, et al. Induction of autophagy is an early response to gefitinib and a potential therapeutic target in breast cancer. PLoS One. 2013;8(10):1–20. doi: 10.1371/journal.pone.0076503. [PMC free article] [PubMed] [CrossRef] [Google Scholar]176. Bokobza SM, et al. Combining AKT inhibition with chloroquine and gefitinib prevents compensatory autophagy and induces cell death in EGFR mutated NSCLC cells. Oncotarget. 2014;5(13):4765–4778. doi: 10.18632/oncotarget.2017. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
177. Zou Y, et al. The autophagy inhibitor chloroquine overcomes the innate resistance of wild-type EGFR non-small-cell lung cancer cells to erlotinib. Journal of Thoracic Oncology : Official Publication of the International Association for the Study of Lung Cancer. 2013;8(6):693–702. doi: 10.1097/JTO.0b013e31828c7210. [PMC free article] [PubMed] [CrossRef] [Google Scholar]178. Bellodi C, et al. Targeting autophagy potentiates tyrosine kinase inhibitor-induced cell death in Philadelphia chromosome-positive cells, including primary CML stem cells. The Journal of Clinical Investigation. 2009;119(5):1109–1123. doi: 10.1172/JCI35660. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
179. Abdel-Aziz AK, et al. Chloroquine synergizes sunitinib cytotoxicity via modulating autophagic, apoptotic and angiogenic machineries. Chemico-Biological Interactions. 2014;217:28–40. doi: 10.1016/j.cbi.2014.04.007. [PubMed] [CrossRef] [Google Scholar]
180. Shimizu S, et al. Inhibition of autophagy potentiates the antitumor effect of the multikinase inhibitor sorafenib in hepatocellular carcinoma. International Journal of Cancer. 2012;131(3):548–557. doi: 10.1002/ijc.26374. [PubMed] [CrossRef] [Google Scholar]
181. Shi Y-H, et al. Targeting autophagy enhances sorafenib lethality for hepatocellular carcinoma via ER stress-related apoptosis. Autophagy. 2011;7(10):1159–1172. doi: 10.4161/auto.7.10.16818. [PubMed] [CrossRef] [Google Scholar]182. Ji C, et al. Induction of autophagy contributes to crizotinib resistance in ALK-positive lung cancer. Cancer Biology & Therapy. 2014;15(5):570–577. doi: 10.4161/cbt.28162. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
183. You L, et al. Crizotinib induces autophagy through inhibition of the STAT3 pathway in multiple lung cancer cell lines. Oncotarget. 2015;6(37):40268–40282. doi: 10.18632/oncotarget.5592. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
184. Mitou G, et al. Targeting autophagy enhances the anti-tumoral action of crizotinib in ALK-positive anaplastic large cell lymphoma. Oncotarget. 2015;6(30):30149–30164. doi: 10.18632/oncotarget.4999. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
185. Shen J, et al. Autophagy inhibition induces enhanced proapoptotic effects of ZD6474 in glioblastoma. British Journal of Cancer. 2013;109(1):164–171. doi: 10.1038/bjc.2013.306. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
186. Hu Y-L, et al. Hypoxia-induced autophagy promotes tumor cell survival and adaptation to antiangiogenic treatment in glioblastoma. Cancer Research. 2012;72(7):1773–1783. doi: 10.1158/0008-5472.CAN-11-3831. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
187. Cufí S, et al. The anti-malarial chloroquine overcomes primary resistance and restores sensitivity to trastuzumab in HER2-positive breast cancer. Scientific Reports. 2013;3:2469. doi: 10.1038/srep02469. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
188. Ratikan JA, et al. Chloroquine engages the immune system to eradicate irradiated breast tumors in mice. International Journal of Radiation Oncology, Biology, Physics. 2013;87(4):761–768. doi: 10.1016/j.ijrobp.2013.07.024. [PubMed] [CrossRef] [Google Scholar]
189. Wei M-F, et al. Autophagy promotes resistance to photodynamic therapy-induced apoptosis selectively in colorectal cancer stem-like cells. Autophagy. 2014;10(7):1179–1192. doi: 10.4161/auto.28679. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
190. Liang X, et al. Inhibiting systemic autophagy during interleukin 2 immunotherapy promotes long-term tumor regression. Cancer Research. 2012;72(11):2791–2801. doi: 10.1158/0008-5472.CAN-12-0320. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
191. Thomas S, et al. Preferential killing of triple-negative breast cancer cells in vitro and in vivo when pharmacological aggravators of endoplasmic reticulum stress are combined with autophagy inhibitors. Cancer Letters. 2012;325(1):63–71. doi: 10.1016/j.canlet.2012.05.030. [PubMed] [CrossRef] [Google Scholar]
192. Harhaji-Trajkovic L, et al. Chloroquine-mediated lysosomal dysfunction enhances the anticancer effect of nutrient deprivation. Pharmaceutical Research. 2012;29(8):2249–2263. doi: 10.1007/s11095-012-0753-1. [PubMed] [CrossRef] [Google Scholar]
193. Thomas R, et al. The effect of chloroquine and hyperthermia on murine neuroblastoma. Journal of Pediatric Surgery. 1990;25(9):929–932. doi: 10.1016/0022-3468(90)90232-X. [PubMed] [CrossRef] [Google Scholar]
194. Gao L, et al. Chloroquine promotes the anticancer effect of TACE in a rabbit VX2 liver tumor model. International Journal of Biological Sciences. 2013;9(4):322–330. doi: 10.7150/ijbs.5925. [PMC free article] [PubMed] [CrossRef] [Google Scholar]
